Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well RPS-160-48 Green Power Supply W 48V 2.3A - Medical Power Supply
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RPS-160-48 Green Power Supply W 48V 2.3A - Medical Power ...
The RPS-160 is a 160W Mean Well power converter (input range: 90~264VAC, operating temperature: -20~+70℃).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 4KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -20~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: ISOLATION LEVEL
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRPS Series
-
Power Rating113.4 Watt
-
Output Voltage48 Volt
-
Rated Current2.3 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,SHIDE
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length5 in
-
Width3 in
-
Height1.36 in
-
Weight0.71 lb
::specification::
Frequently Asked Questions
Can I use the RPS-160-48 for a 48V industrial control or automation system?
Yes, this model is a constant-voltage 48V supply rated for 2.3A and 113.4W, which fits 48V industrial control loads that need a stable DC bus. It is better suited to protected equipment inside industrial or automation enclosures than to exposed field use because no IP rating is listed.
Is the RPS-160-48 suitable for 48V embedded or telecom-style electronics?
It can be a fit for 48V embedded and communications equipment that operates within a 2.3A load limit. The wide 90-264VAC input also helps when the same product may be used across different AC mains environments.
Can this power supply be used in medical electronic equipment?
Yes, the product is described as a medical power supply and is listed as medical safety approved. It also carries CB, CE, cUL, EAC, and c_shide certifications, which can matter for regulated equipment builds.
Would the RPS-160-48 work for a 48V lab, test, or instrumentation system?
It is appropriate for 48V instrumentation or bench equipment that needs constant-voltage output up to 2.3A. The compact 127.0 x 76.2 x 34.6 mm form factor can also help where internal space is limited.
Can the RPS-160-48 be used outdoors or in harsh environments?
The operating temperature range is -20°C to +70°C, so the temperature spec covers a broad indoor operating range. However, no IP rating is listed, so it should be treated as a protected indoor power supply rather than an exposed outdoor unit.
How does the RPS-160-48 compare with nearby 48V models in the RPS series?
Within nearby 48V siblings, the RPS-120-48 and RPS-120-48-C are 84W at 48V 2.5A, the RPS-120S-48 is 120W at 48V 2.5A, this RPS-160-48 is 113.4W at 48V 2.3A, and the RPS-200-48 and RPS-200-48-C are 144W at 48V 3A. Higher up the range, the RPS-300-48 and RPS-300-48-C are 200.2W at 48V 4.17A, the RPS-400-48 variants are 254.4W at 48V 5.3A, and the RPS-500-48 variants reach 321.6W, 312W, or 499.2W at 48V.
