Mean Well RQB60W12-110S05 1/4 Brick, 14-160VDC Ultra Wide Input Rai...
The RQB60W12 is a 60W Mean Well power converter (input range: 14~160Vdc).
Key Features
- ✓ Input voltage range: 14~160Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature / Under voltage
- ✓ Railway standards: EN45545-2 (fire), EN50155 / IEC60571, IEC61373 (shock & vibration)
- ✓ Remote ON/OFF control
- ✓ Safety approvals: CB IEC62368-1, UL62368-1, EAC TP TC 020/2011
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRQB60W12 Series
-
Power Rating60 Watt
-
Output Voltage54 Volt
-
Rated Current1.11 Ampere
-
Input Voltage14V~160V
-
No of Output1
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length2.28 in
-
Width1.45 in
-
Height0.5 in
-
Weight0.15 lb
::specification::
Frequently Asked Questions
What type of power product is the Mean Well RQB60W12-110S54?
The RQB60W12-110S54 is a 60W railway DC-DC converter in a 1/4 brick form factor. It is designed for DC input applications that need a regulated 54V DC output from an ultra-wide DC input range.
What input voltage range does the RQB60W12-110S54 support?
This model supports an ultra-wide 14 to 160VDC input range. That 12:1 range makes it suitable for demanding DC power environments where input voltage can vary significantly.
What are the output specifications of this converter?
The RQB60W12-110S54 provides a nominal 54V DC output with a 60W power rating. Its rated output current is 1.111A, and the output can be trimmed by plus or minus 10 percent.
Is the RQB60W12-110S54 suitable for railway or rolling stock applications?
Yes. This converter is described as compliant with EN50155 and designed to meet EN45545-2, which are relevant railway standards. That makes it a strong fit for railway-related DC power applications where ruggedness and compliance matter.
Can this DC-DC converter handle harsh temperature conditions?
Yes. The specified operating temperature range is -40°C to +90°C, which supports use in demanding industrial and transport environments. Its fully encapsulated construction also helps support durability in tougher conditions.
What protection and control features are included in this model?
The RQB60W12-110S54 includes protection for short circuit, overload, over temperature, over voltage, and input under voltage. It also provides remote ON/OFF control, remote sense, and 3KVDC or 2KVAC input-to-output isolation.
