Boxco S-Series 7.48 x 7.48 x 5.12 Inches(190x190x130mm) Plastic Enclosure, IP67, IK08, ABS, Transparent Cover, Screw Type
Notify me when it's back in stock
Your order will be processed within 24 hours
Boxco S-Series 7.48 x 7.48 x 5.12 Inches(190x190x130mm) Plastic Enc...
For Boxco S-Series, Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.
Features
- Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
- Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
- Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
- Cover Bolt Attachment Point – Screw thread was made in injection molding to ensure maximum strength
-
BrandBoxco
-
SeriesBoxco S Series
-
MaterialABS
-
Base ColorGrey
-
Cover ColorTransparent
-
Standards MetCE,TUV,UL
-
Operating Temperature-40°C~70°C
-
Warranty1 Year
-
Length7.48 in
-
Width7.48 in
-
Height5.12 in
-
Weight3 lb
::specification::
Frequently Asked Questions
What is this Boxco S-Series enclosure typically used for?
This enclosure is designed to protect electronic components and instruments in industrial and commercial applications where a sealed plastic housing is needed. Its anti-static material and high-impact ABS construction make it a practical choice for housing sensitive equipment in demanding environments.
What are the key specifications of the BC-ATS-191913 enclosure?
This model measures 7.48 x 7.48 x 5.12 inches (190 x 190 x 130 mm) and is made from ABS with a transparent screw-type cover. It is rated IP67 for dust and water protection, IK08 for impact resistance, weighs 1.36 kg, and has an operating temperature range of -40 C to 70 C.
Is this enclosure suitable for outdoor or harsh environments?
Yes, this Boxco S-Series enclosure includes an ultraviolet stabilizer to support outdoor use and reduce noticeable color change over time. Its IP67 rating helps protect against dust and water ingress, while the IK08 impact rating supports use in tougher environments.
Does this enclosure support mounting internal components securely?
Yes, the enclosure includes internal mounting plate attachment points with brass inserted injection molding to help secure heavier equipment inside. It also features pre-molded mounting screw nuts for attaching compatible internal hardware such as DIN rail-based components.
What makes this model different from a basic plastic enclosure?
This model combines ABS construction, anti-static material, UV stabilization, a transparent cover, and both IP67 and IK08 ratings in one enclosure. It also includes built-in features such as gasket sealing, molded cover bolt attachment points, and internal mounting support that may not be present on simpler enclosures.
Does the transparent cover affect the enclosure's protection rating?
This model is specified with a transparent cover while still carrying an IP67 and IK08 rating. That means the cover is part of the enclosure's designed protection against dust, water ingress, and external impact for this specific model.
