Mean Well DKMW30F-12 DC-DC Converter - 30W - 9~36V in ±12V out
The DKMW30F is a 30W Mean Well. power converter. and an input range of 9~36Vdc.
Key Features
- ✓ Input voltage range: 9~36Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKMW Series
-
Power Rating30 Watt
-
Output Voltage12 Volt
-
Rated Current1.25 Ampere
-
Input Voltage9V~36V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can I use the DKMW30F-12 in a 12V vehicle or battery-based control system?
It is suited to systems with a 9-36V input range that need a 12V constant-voltage output. That makes it relevant for 12V, 24V, or other DC platforms that fall inside that input window. The converter is rated for 30W with 1.25A output current.
Is this model suitable for industrial electronics powered from a 24V DC bus?
Yes. A 24V source sits inside the 9-36V input range, and the converter provides a 12V constant-voltage output. With a 30W rating in a 25.4 × 25.4 × 10.2 mm package, it fits lower-power industrial electronics that need voltage conversion on a compact footprint.
Can the DKMW30F-12 power embedded or automation modules that need regulated 12V?
Yes, if the modules require 12V constant-voltage power and the load stays within 30W and 1.25A. The 9-36V input range is useful in embedded and automation designs where the available DC supply can vary. Its small size also supports dense layouts.
Is the DKMW30F-12 appropriate for outdoor equipment cabinets?
The operating temperature range of -40°C to +85°C supports wide thermal conditions, but no IP rating is listed for this converter. That means it should not be treated as a weather-exposed or washdown product on its own. A protected enclosure is the better match when environmental sealing is required.
What is the difference between the DKMW30F-12 and DKMW30F-15?
Both are 30W converters with a 9-36V input range, 25.4 × 25.4 × 10.2 mm dimensions, 0.018 kg weight, -40°C to +85°C operating temperature, CE certification, and a 3-year warranty. The DKMW30F-12 provides 12V output at 1.25A, while the DKMW30F-15 provides 15V output at 1A. The input range and package are the same, but the output voltage and current differ.
