Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Boxco Push Button Box, 3.15 x 5.12 x 2.76 Inches(80 x 130 x 70mm) 2...
Boxco push button enclosures are made from ABS and polycarbonate material. It has 1-3 push button entries and molded knock outs in base for easy installation. This product does not require additional machining when installing 22, 25 or 30 push button and switches.
Features
- Screw type
- This series has a pre-cut hole on the cover
-
BrandBoxco
-
SeriesBoxco S Series
-
MaterialABS
-
Base ColorGrey
-
Cover ColorGrey
-
Standards MetCE,DIN,ROHS,TUV
-
Operating Temperature-40°C~85°C
-
Warranty1 Year
-
Length3.15 in
-
Width5.12 in
-
Height2.76 in
-
Weight1.1 lb
::specification::
Frequently Asked Questions
What are the main specifications of this Boxco push button box?
This model is a Boxco push button box with overall dimensions of 3.15 x 5.12 x 2.76 inches (80 x 130 x 70 mm). It has a 2-hole cover, an IP67 ingress protection rating, an IK08 impact rating, and an ABS construction with a grey cover.
What types of applications is this enclosure best suited for?
This enclosure is intended for push button and switch applications where a compact, durable housing is needed. Its 2-hole cover makes it a fit for control stations or equipment interfaces that require two operator devices in one enclosure.
Does this model require extra machining for standard push buttons?
Boxco states that this product does not require additional machining when installing 22, 25, or 30 push buttons and switches. This helps reduce prep work for applications using those common device sizes.
How well does this enclosure hold up in harsh environments?
This model is rated IP67 for protection against dust and temporary water immersion, and IK08 for impact resistance. It is also specified for temperatures from -40°C to 85°C, making it suitable for demanding industrial environments within that range.
What makes this model different from a plain utility enclosure?
Unlike a plain enclosure box, this series is designed specifically for push button use and includes a pre-cut hole arrangement on the cover. That makes it more purpose-built for operator interface applications than a standard blank box.
What material is this push button box made from?
The product listing identifies this model as ABS with a grey cover. The series description also notes Boxco push button enclosures are made from ABS and polycarbonate material, but this specific model is identified as ABS in the provided specifications.
