Boxco Push Button Box, 3.15 x 7.09 x 2.76 Inches(80 x 180 x 70mm) 3...
Boxco push button enclosures are made from ABS and polycarbonate material. It has 1-3 push button entries and molded knock outs in base for easy installation. This product does not require additional machining when installing 22, 25 or 30 push button and switches.
Features
- Screw type
- This series has a pre-cut hole on the cover
-
BrandBoxco
-
SeriesBoxco S Series
-
MaterialABS
-
Base ColorGrey
-
Cover ColorGrey
-
Standards MetCE,DIN,ROHS,TUV
-
Operating Temperature-40°C~85°C
-
Warranty1 Year
-
Length3.15 in
-
Width7.09 in
-
Height2.76 in
-
Weight1.1 lb
::specification::
Frequently Asked Questions
What is this Boxco push button box designed for?
This model is intended for control-panel and machine-interface applications where a sealed push button enclosure is needed. It is a 3-hole push button box with a screw-type design, making it suited to builds that need a dedicated enclosure rather than a plain utility box.
What push button sizes is this enclosure compatible with?
According to the product description, this enclosure does not require additional machining for 22 mm, 25 mm, or 30 mm push buttons and switches. This specific model has 3 pre-cut holes on the cover for that purpose.
What are the main specifications of this enclosure?
This Boxco enclosure measures 3.15 x 7.09 x 2.76 inches, which is 80 x 180 x 70 mm. It has an IP67 ingress rating, IK08 impact rating, ABS construction with a grey cover, and a listed weight of 0.5000 kg.
Can this push button box handle demanding environments?
This model is rated IP67 for dust-tight and water-resistant protection and IK08 for impact resistance, so it is built for more demanding industrial environments than a basic enclosure. Its operating temperature range is -40 degrees C to 85 degrees C, which supports use in both cold and hot conditions.
How is this model different from a standard blank enclosure?
This version is made specifically for push button applications, with 3 pre-cut cover holes and molded knockouts in the base. That makes it a more purpose-built option than a blank enclosure that would need separate cover preparation for button cutouts.
