Mean Well XDR-150E-12 Economical Ultra Slim Din Rail Power Supply 1...
Key Features
- ✓85~264Vac input range
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010)
- ✓30mm slim width
- ✓High efficiency up to 91% and no-load power dissipation<1W
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Overvoltage category III (OVC III)
- ✓-40°~+70°C wide range operation temperature (>+50°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in DC OK relay contact
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓3 years warranty
-
BrandMean Well
-
SeriesMean Well XDR Series
-
Power Rating120 Watt
-
Output Voltage12 Volt
-
Rated Current10 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC
-
Operating Temperature-40°C~70°C
-
Warranty3 Year
-
Length4.57 in
-
Width1.18 in
-
Height4.93 in
-
Weight0.95 lb
::specification::
Frequently Asked Questions
What is the output rating of the Mean Well XDR-150E-12?
The XDR-150E-12 is rated for 12V DC output at 10A. Based on the provided product specifications, its listed power rating is 120W.
Is the XDR-150E-12 suitable for space-limited control panels?
Yes. This model is an ultra slim DIN rail power supply with a 30mm width, making it suitable for compact industrial control cabinets and other space-constrained equipment layouts.
What input voltage range does the XDR-150E-12 support?
The XDR-150E-12 supports an 85-264Vac input range. This wide input range helps make the model practical for global equipment designs where compatible AC mains input is required.
What operating temperature range is specified for this model?
The specified operating temperature range is -40°C to +70°C. Operation above +50°C requires derating according to the product description.
Does the XDR-150E-12 use a fan?
No. The XDR-150E-12 uses a fanless design with cooling by free air convection, which can help reduce noise and avoid fan-maintenance concerns in suitable environments.
What protection features are listed for the XDR-150E-12?
The listed protections are short circuit, overload, over voltage, and over temperature. It also includes a built-in constant current limiting circuit.
How does the XDR-150E-12 differ from a larger DIN rail power supply?
The key differentiator in the provided specifications is its 30mm slim width. It is a better fit when the buyer needs a 12V, 10A DIN rail supply in a narrower form factor rather than simply choosing a physically larger unit.
What warranty period is provided for the XDR-150E-12?
The XDR-150E-12 has a listed warranty period of 3 years. This warranty period applies to the model as specified in the provided product data.
