Mean Well A301-1K0-B2 Modified sine wave 1000W 110V - DC-AC Inverter
modified sine wave, suitable for resistive load, low cost
SKU:
A301-1K0-B2
$205.61 USD
Unit price /
Unavailable
Shipping calculated at checkout.
|
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well A301-1K0-B2 Modified sine wave 1000W 110V - DC-AC Inverter
$205.61 USD
Unit price /
Unavailable
Description
Description
Features
| 12V or 24V DC input |
| Power ON-OFF switch |
| Input voltage range: -15% ~ +25% |
| Output voltage regulation ±10% |
| Protections: Input reverse polarity/Bat. low shutdown/Over voltage/ Overload/Over temperature/Output short |
| Output waveform: Modified sine wave |
| Cooling fan ON-OFF control |
| ON/OFF remote control(Optional) |
| Approvals: E13 / EAC / CE / UKCA |
| 1 year warranty |
General Specification
| AC output voltage range | 110V |
| AC output waveform | Modified sine wave |
| Overload temperature | 60±5℃ / 140±9°F |
| Overvoltage | 125~133% load |
| Output short | Shut-off |
| Working temperature | 0 ~ 30°C@ 100% load, 40°C@ 50% load |
| Safety standards | EAC TP TC 004 approved |
| EMC standards | IEC61000-4-2,3, EAC TP TC 020 |
| Dimension (LxWxH) | 310*210*85mm |
| Packing | 4pcs / 17.5kg |
Specifications
Specifications
-
BrandMean Well
-
SeriesA301/A302 Series
-
Power Rating1000 Watt
-
Output Voltage110 Volt
-
Input Voltage10V~15V
-
No of Output1
-
Standards MetCE,E13,EAC
-
Operation ModeConstant Voltage
-
Operating Temperature0°C~30°C
-
Warranty1 Year
-
Length12.2 in
-
Width8.27 in
-
Height3.35 in
-
Weight7.28 lb
