Mean Well HLG-60H-48 Power Supply 60W 48V
Description
Description
The HLG-60H is a 60W Mean Well power converter (input range: 90~305VAC).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.8 SAFETY &
- ✓ 3 years warranty
Specifications
Specifications
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating60 Watt
-
Output Voltage48 Volt
-
Rated Current1.3 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty7 Year
-
Length6.73 in
-
Width2.42 in
-
Height1.45 in
-
Weight1.61 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
Can I use the HLG-60H-48 to power 48V LED panel lights?
Yes. The HLG-60H-48 provides 48V at up to 1.3A (60W), which is a common configuration for commercial 48V LED panel lights. It operates in constant-current mode across a 28-48V range, so it can handle panels with slightly varying voltage requirements. Note that this is a fixed-output model with no dimming or adjustment.
Is the HLG-60H-48 a good driver for 48V LED modules in outdoor signage?
Yes, provided total power stays within 60W. Its IP67 waterproof rating and aluminium casing protect it from rain, dust, and temperature extremes (-40°C to +80°C). This makes it reliable for outdoor sign cabinets or channel letters using 48V LED modules.
Can the HLG-60H-48 power 48V LED lighting in a greenhouse?
Yes. At 60W and 48V with IP67 waterproofing, the HLG-60H-48 can handle the high humidity and occasional water exposure found in greenhouses. The wide operating temperature range of -40°C to +80°C also accommodates the heat that greenhouse environments can reach.
How many meters of 48V LED strip can the HLG-60H-48 drive?
Divide 60W by your strip's rated power per meter. A 48V strip at 10W/m allows up to 6 meters (60W / 10W per meter = 6m). A denser strip at 20W/m allows 3 meters. Always check your strip's rated power per meter and keep total load at or below 60W.
Can the HLG-60H-48 be used in a permanently wet outdoor location?
Yes. The IP67 rating means the unit is dust-tight and can withstand temporary immersion up to 1 meter. It is suitable for installations exposed to heavy rain, sprinkler zones, or areas where standing water may briefly occur. The -40°C to +80°C operating range handles year-round outdoor conditions.
What are the differences between the HLG-60H-48, 48A, 48AB, and 48B?
All four models output 60W at 48V / 1.3A with a CC range of 28-48V. The base HLG-60H-48 has fixed output and IP67 waterproofing. The -48A adds output adjustment via potentiometer (IP65). The -48AB adds both adjustment and 1-10V/PWM dimming (IP65). The -48B provides dimming input only and retains IP67.
