Mean Well XTR-480-48 Three Phase Din Rail Power Supply 480W 48V - Screw Terminal
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well XTR-480-48 Three Phase Din Rail Power Supply 480W 48V - S...
Description
Description
The XTR-480 series offers 480W of power in an ultra-slim design, making it suitable for a range of industrial applications. It features advanced protection mechanisms and remote control capabilities, which enhance its reliability and operational flexibility. This model is perfect for demanding environments requiring efficient power delivery and robust performance.
Key Features:
- Three-Phase 320 ~ 600Vac wide range input (Dual phase operation possible)
- High efficiency up to 95.5% and no load power dissipation <3.1W
- 200% Peak Power capability
- Built-in constant current limiting circuit
- Certifications: SEMI47, C1D2 HazLoc approved
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Remote on/off control
- Operating temperature range: -40~+85°C
- Built-in DC OK relay contact
- Tool free terminal block (LA type)
Specifications
Specifications
-
BrandMean Well
-
SeriesMean Well XTR Series
-
Power Rating480 Watt
-
Output Voltage48 Volt
-
Rated Current10 Ampere
-
Input Voltage320V~600V
-
No of Output1
-
Standards MetCB,CCC,CE,EAC,EN,KC
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length4.92 in
-
Width2.48 in
-
Height4.93 in
-
Weight2.87 lb
