Mean Well EPP-300-27 Power Supply 200W 27V 7.4A
The EPP-300 is a 199.8W Mean Well open-frame power supply (input: 90~264VAC, operating temperature: -30~+70°C).
Key Features
- ✓ Input voltage: 90~264VAC
- ✓ Output voltage (max): 27V
- ✓ Rated output current: 7.4A
- ✓ Operating temperature: -30~+70°C
- ✓ Active PFC — meets international energy efficiency standards
- ✓ Safety certifications: CB, CE, EAC, TÜV, UL
- ✓ 3 year warranty
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating199.8 Watt
-
Output Voltage27 Volt
-
Rated Current7.4 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length5 in
-
Width3 in
-
Height1.38 in
-
Weight0.82 lb
::specification::
Frequently Asked Questions
Can I use the EPP-300-27 for equipment that specifically requires 27V DC?
Yes, if the load is designed for constant 27Vdc input and does not exceed 199.8W or 7.4A. This unit should be matched to equipment that explicitly calls for 27V rather than nearby DC voltages.
Is the EPP-300-27 suitable for 27V industrial control or embedded subsystems?
It can be used for 27Vdc control or embedded loads when the total requirement stays within the 7.4A and 199.8W limits. The 90-264VAC input range can also help in mixed-site industrial deployments.
Can this power supply run a 27V instrumentation or test fixture load?
It is appropriate for 27V instrumentation, fixtures, or specialty electronics that need a constant-voltage output and stay under 199.8W. The fixed 27V output is the key compatibility point, with current capacity available up to 7.4A.
Is the EPP-300-27 rated for outdoor service?
The unit is specified for operation from -30 degrees C to +70 degrees C, which covers a wide temperature span. However, the provided specs do not list an IP rating, so they do not confirm outdoor, wet-location, or dust-exposed suitability.
How does the EPP-300-27 compare with other 27V EPP power supplies?
The listed 27V siblings are EPP-100-27 at 75.6W and 2.8A, EPP-120S-27 at 119.9W and 4.44A, EPP-150-27 at 100.17W and 3.71A, EPP-200-27 at 143.1W and 5.3A, this EPP-300-27 at 199.8W and 7.4A, EPP-400-27 at 251.1W and 9.3A, and EPP-500-27 at 321.3W and 11.9A. It sits between the 143.1W and 251.1W classes in the 27V branch of the series.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other EPP-300 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well EPP-300-48 Power Supply 200W 48V 4.17A | 200.2W | 48V | 4.17A | Indoor | $64.48 | View |
| Mean Well EPP-300-24 Power Supply 200W 24V 8.33A | 199.9W | 24V | 8.33A | Indoor | $65.64 | View |
| Mean Well EPP-300-15 Power Supply 200W 15V 13.33A | 200W | 15V | 13.33A | Indoor | $65.76 | View |
| Mean Well EPP-300-12 Power Supply 200W 12V 16.67A | 200W | 12V | 16.67A | Indoor | $60.28 | View |
