Mean Well RS-100-15 Power Supply 100W 15V
The RS-100 is a Mean Well DIN rail power converter with a 59mm profile (input range: 125~373VDC).
Key Features
- ✓ 59mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 125~373VDC
- ✓ Cooling by free air convection — no minimum load required
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: UL62368 TUV EN62368-~ EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRS Series
-
Power Rating105 Watt
-
Output Voltage15 Volt
-
Rated Current7 Ampere
-
Input Voltage88V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length6.26 in
-
Width3.82 in
-
Height1.5 in
-
Weight1.32 lb
::specification::
Frequently Asked Questions
Can I use the RS-100-15 for a 15V industrial control or instrumentation load?
Yes, it is a constant-voltage 15V power supply rated for 7A and 105W. That makes it suitable for enclosed industrial or instrumentation loads that are specified for 15V and stay within those limits.
Is the RS-100-15 suitable for embedded systems or test equipment that require 15V DC?
It can fit embedded electronics or test equipment that need a regulated 15V rail up to 7A. The 88-264VAC input also supports equipment used across a wide AC input range.
Can this power supply run a 15V automation subsystem inside a compact cabinet?
It is appropriate for enclosed automation hardware that needs 15V constant voltage and does not exceed 7A or 105W. Its 159.0 × 97.0 × 38.0 mm dimensions and 0.6 kg weight are helpful where panel space is limited.
Can the RS-100-15 be used in harsh indoor environments?
The provided specs list operation from -25°C to +70°C and note 5G vibration resistance. No IP rating is listed, so the stated data supports protected indoor industrial environments rather than exposed washdown or outdoor locations.
How does the RS-100-15 compare with other RS-100 versions?
The listed RS-100 models are RS-100-3.3 at 66W 3.3V 20A, RS-100-5 at 80W 5V 16A, RS-100-12 at 102W 12V 8.5A, RS-100-15 at 105W 15V 7A, RS-100-24 at 108W 24V 4.5A, and RS-100-48 at 110.4W 48V 2.3A. RS-100-12-OB appears in the family list, but no output figures are provided for it in the supplied specs.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other RS-100 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well RS-100-5 Power Supply 100W 5V | 80W | 5V | 16A | Indoor | $27.40 | View |
| Mean Well RS-100-48 Power Supply 100W 48V | 110.4W | 48V | 2.3A | Indoor | $27.40 | View |
| Mean Well RS-100-3.3 Power Supply 100W 3.3V | 66W | 3.3V | 20A | Indoor | $27.39 | View |
| Mean Well RS-100-24 Power Supply 100W 24V | 108W | 24V | 4.5A | Indoor | $27.40 | View |
| Mean Well RS-100-12 Power Supply 100W 12V | 102W | 12V | 8.5A | Indoor | $27.40 | View |
