Mean Well DET01L-12 DC-DC Converter - 1W 5V DC in 12V out
The DET01L is a 1W Mean Well. power converter. and an input range of 4.5~5.5V.
Key Features
- ✓ Input voltage range: 4.5~5.5V
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+85℃
- ✓ Protections: Short circuit / Overload
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.04 Ampere
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetBSMI,CB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty1 Year
-
Length5.91 in
-
Width3.94 in
-
Height0.79 in
-
Weight2.2 lb
::specification::
Frequently Asked Questions
What does the Mean Well DET01L-12 do?
The DET01L-12 is a 1W DC-DC converter designed to convert 5V DC input to 12V DC output. It is intended for low-power DC power conversion in compact electronic equipment.
What are the main electrical specifications of the DET01L-12?
This model is rated for 1W output power and provides a 12V DC output. Its rated output current is 0.042A, and the product name identifies it as a 5V DC input, 12V DC output converter.
Is the DET01L-12 suitable for electrically isolated applications?
Yes. The DET01L-12 provides 3000VDC input-to-output isolation, which can be important in designs that require separation between input and output circuits. That makes it a stronger choice than non-isolated DC-DC converters for applications where isolation is required.
What protection and reliability features are included in this converter?
The DET01L-12 includes short-circuit protection and is built using internal SMD technology. It also undergoes a 100% full-load burn-in test and is described as a low-cost, high-reliability model.
What operating temperature range does the DET01L-12 support?
This model is specified for operation from -40°C to 85°C. That wide temperature range makes it suitable for use in demanding industrial or embedded environments where ambient conditions can vary significantly.
What approvals and warranty does the Mean Well DET01L-12 have?
The DET01L-12 is approved to UL and CUL standards. It also includes a 1-year warranty from the manufacturer.
