Mean Well DPU01M-05 DC-DC Converter - 1W - 10.8~13.2V in ±5V out
The DPU01M is a 1W Mean Well power converter (input range: 4.5~5.5Vdc).
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDPU Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.1 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~125°C
-
Warranty3 Year
-
Length0.77 in
-
Width0.4 in
-
Height0.28 in
-
Weight0.01 lb
::specification::
Frequently Asked Questions
Can I use the DPU01M-05 in a compact industrial control board that needs a 5V rail?
This model is a 1W constant-voltage converter with 10.8~13.2V input and 5V output. Its 19.6 × 10.2 × 7.1 mm package fits space-constrained embedded and industrial control designs where a low-power 5V rail is needed.
Is the DPU01M-05 suitable for low-power embedded electronics in a 12V-class system?
It is designed for 10.8~13.2V input and provides a regulated 5V output at 1W. That makes it a fit for embedded electronics that operate within that input range and need constant-voltage output rather than higher-power conversion.
Can this converter be used in instrumentation or automation modules with very limited board space?
Yes, the DPU01M-05 is aimed at compact designs because it measures 19.6 × 10.2 × 7.1 mm and weighs 0.0027 kg. Its 1W rating also aligns with low-power instrumentation and automation subcircuits instead of larger loads.
Is the DPU01M-05 appropriate for outdoor or high-temperature environments?
The listed operating temperature is -55°C to +125°C, which supports very wide temperature conditions. No IP rating is provided in the specs, so the product data does not confirm outdoor or exposed-environment use.
How does the DPU01M-05 compare with the other DPU01M models?
The DPU01M-05, DPU01M-12, and DPU01M-15 are all 1W models in the same 19.6 × 10.2 × 7.1 mm package with 10.8~13.2V input, -55°C to +125°C operation, CE certification, and a 3-year warranty. The difference is output: DPU01M-05 is 5V with listed output current 100A, DPU01M-12 is 12V at 0.04A, and DPU01M-15 is 15V at 0.03A.
