Mean Well EPP-300-15 Power Supply 200W 15V
No load power consumption under 0.5W by PS-ON control
<2mA/240VAC
Key Features
- ✓✓Universal AC input / Full range
- ✓✓Built-in active PFC function
- ✓✓High efficiency up to 93%
- ✓✓Withstand 300VAC surge input for 6 secondsNo load power consumption<0.5W5"x3" compact sizeHigh efficiency up to 94%
- ✓✓Protections: Short circuit/Overload/Over voltage/Over temperature
- ✓✓Cooling by free air convection for 200W and 300W with 20.5 CFM forced airWith power good and fail signal outputBuilt-in remote sense function
- ✓✓No load power consumption under 0.5W by PS-ON control
- ✓✓Standby 5V@1A with fan, @ 0.6A without fan
- ✓✓Operating altitude up to 5000 meters
- ✓✓3 years warranty
-
BrandMean Well
-
SeriesEPP Series
-
Power Rating200 Watt
-
Output Voltage15 Volt
-
Rated Current13.33 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length5 in
-
Width3 in
-
Height1.38 in
-
Weight0.82 lb
::specification::
Frequently Asked Questions
Can I use the EPP-300-15 for 15V industrial test equipment or bench fixtures?
Yes, if the equipment is designed for a constant 15Vdc input and stays within 200W and 13.33A. This is a fixed-voltage supply, so it should only be paired with loads that specifically call for 15V.
Is the EPP-300-15 suitable for embedded hardware that runs on 15V DC?
It can be a match for embedded assemblies, controllers, or subsystems that require regulated 15V constant-voltage power and draw up to 13.33A. The 90-264VAC input range is also useful where the AC source can vary between installations.
Can this model support a 15V automation or instrumentation load?
It is appropriate for 15Vdc instrumentation or automation loads when the total draw remains at or below 200W and 13.33A. Because the output is constant voltage, the connected device should be specified for 15V operation rather than a nearby nominal voltage.
Is the EPP-300-15 intended for outdoor use?
The published operating temperature is -30 degrees C to +70 degrees C, which covers a wide thermal range. However, no IP rating is listed in the provided specs, so outdoor exposure or wet-location use is not established here.
How does the EPP-300-15 fit into the 15V EPP lineup?
The listed 15V siblings are EPP-100-15 at 75W and 5A, EPP-120S-15 at 114W and 7.6A, EPP-150-15 at 100.5W and 6.7A, EPP-200-15 at 141W and 9.4A, this EPP-300-15 at 200W and 13.33A, EPP-400-15 at 250.5W and 16.7A, and EPP-500-15 at 319.5W and 21.3A. In that progression, this model sits above the 141W class and below the 250.5W and 319.5W versions.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other EPP-300 Models
4 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well EPP-300-48 Power Supply 200W 48V | 200.2W | 48V | 4.17A | Indoor | $62.34 | View |
| Mean Well EPP-300-27 Power Supply 200W 27V | 199.8W | 27V | 7.4A | Indoor | $65.64 | View |
| Mean Well EPP-300-24 Power Supply 200W 24V | 199.9W | 24V | 8.33A | Indoor | $64.84 | View |
| Mean Well EPP-300-12 Power Supply 200W 12V | 200W | 12V | 16.67A | Indoor | $52.90 | View |
