Mean Well HBG-100-36 Power Supply 100W 36V
The HBG-100 is a 100W Mean Well power converter (input range: 14.4~24V).
Key Features
- ✓ Input voltage range: 14.4~24V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating97.2 Watt
-
Output Voltage37 Volt
-
Rated Current2.7 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.12 in
-
Width5.12 in
-
Height2.62 in
-
Weight2.6 lb
::specification::
Frequently Asked Questions
Can the HBG-100-36 power a constant current LED downlight module?
Yes, if the downlight module is built for constant current operation and its total forward voltage is within the 21-36V CC range. It is not intended for constant voltage 36V lighting products that expect a fixed-voltage supply.
Is the HBG-100-36 suitable for a signage light engine with a higher forward voltage than 24V models?
Yes, this version is better suited to constant current signage or display light engines that need a 21-36V operating range. It should still be matched by forward voltage and 97.2W power, not by assuming a fixed number of LEDs.
Can I use this driver for a small LED array in a commercial fixture?
Yes, it can be used for a small LED array when the array is a constant current load that stays within the 21-36V CC window and the 97.2W rating. The product is also described for high/low bay light use, which aligns with integrated fixture applications.
Would the HBG-100-36 work in outdoor or harsh industrial conditions?
Yes, it is rated IP67 waterproof and operates across -40°C to +85°C. That supports use in wet, dusty, or temperature-challenging environments where a sealed driver is preferred.
How do I check LED compatibility with the HBG-100-36?
Match it to a constant current LED load whose total forward voltage falls within the 21-36V CC output range. The number of LEDs depends on the forward voltage of each LED, so compatibility should be based on total LED forward voltage rather than a fixed LED count.
How does the HBG-100-36 differ from the 24V, 48V, and 60V versions?
This 36V branch is rated 97.2W with 2.7mA output current and a 21-36V CC range. The 24V branch is 96W with 4mA and 14-24V, the 48V branch is 96W with 2mA and 28-48V, and the 60V branch is 96W with 1.6mA and 36-60V.
