Mean Well HBG-100-36DA Power Supply 100W 36V - DALI
The HBG-100 is a 100W Mean Well power converter (input range: 14.4~24V).
Key Features
- ✓ Input voltage range: 14.4~24V
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHBG Series
-
Power Rating97.2 Watt
-
Output Voltage37 Volt
-
Rated Current2.7 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlDALI
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length5.12 in
-
Width5.12 in
-
Height2.62 in
-
Weight2.6 lb
::specification::
Frequently Asked Questions
Can I use the HBG-100-36DA for LED downlights that need a constant current driver?
Yes, this unit is a constant current driver rated at 97.2W with a 21-36V CC output range. It is intended for LED loads that are specified for constant current operation, not constant voltage operation.
Will the HBG-100-36DA work for a small LED array in a commercial luminaire?
It can, as long as the array is designed for constant current and its operating voltage stays within the 21-36V CC range. The number of LEDs depends on the forward voltage of each LED, so compatibility is determined by the array voltage rather than a fixed LED count.
Is this driver appropriate for signage modules that need reliable outdoor protection?
The HBG-100-36DA carries an IP67 waterproof rating, so it is suited to signage and other lighting assemblies exposed to wet conditions. Its -40°C to +85°C operating range also supports use in harsh environments within that temperature band.
Can the HBG-100-36DA be used in high bay or low bay LED fixtures?
Yes, the listed features specifically note use for high and low bay lighting, and the circular housing supports that style of fixture design. The LED engine still needs to match the 21-36V constant current range and 97.2W rating.
What is the difference between the HBG-100-36DA and the other HBG-100 series output classes?
Across the HBG-100 family, the main electrical groups are 14-24V at 4mA and 96W, 21-36V at 2.7mA and 97.2W, 28-48V at 2mA and 96W, and 36-60V at 1.6mA and 96W. The HBG-100-36DA belongs to the 21-36V, 2.7mA, 97.2W group, which is shared by the other 36-series versions.
