Mean Well HEP-150-15A Power Supply 150W 15V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-150-15A Power Supply 150W 15V
The HEP-150 is a 150W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC, operating temperature: -60~+80°C).
Key Features
- ✓ 228mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -60~+80°C
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-150 Blank type), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating150 Watt
-
Output Voltage15 Volt
-
Rated Current10 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can the HEP-150-15A be used for 15V factory control panels or OEM equipment?
Yes, for applications that need constant voltage 15V and stay within 150W and 10A. Its 90-305VAC input, fanless design, and -55°C to +70°C operating range fit demanding industrial and OEM environments.
Is this power supply a fit for 15V embedded controllers or communications hardware?
It can be used for 15V embedded or communications hardware that requires up to 10A from a constant voltage source. The fanless build, rugged metal case, and 10G vibration resistance are useful where reliability matters more than open-air cooling.
Can I use the HEP-150-15A for 15V LED or low-voltage electronic loads?
Yes, if the load is designed for constant voltage 15V and does not exceed 150W or 10A. This model is better suited to harsher locations than a standard indoor supply because it is IP65 water-resistant and built for -55°C to +70°C operation.
Is the HEP-150-15A good for outdoor installations?
It is suitable for many outdoor or industrial locations because it has an IP65 water-resistant enclosure and operates from -55°C to +70°C. IP65 indicates resistance to dust and water exposure, but it is not the same as an IP68-rated version.
What is the difference between the HEP-150-15A and HEP-150-15, and how do they compare with the rest of the 150 series?
HEP-150-15A and HEP-150-15 share the same electrical rating at 150W, 15V, and 10A. The rest of the 150-size family includes HEP-150-12 and HEP-150-12A at 150W, 12V, 12.5A; HEP-150-24 and HEP-150-24A at 151.2W, 24V, 6.3A; HEP-150-36 and HEP-150-36A at 151.2W, 36V, 4.2A; HEP-150-48 and HEP-150-48A at 153.6W, 48V, 3.2A; and HEP-150-54 and HEP-150-54A at 151.2W, 54V, 2.8A.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other HEP-150 Models
2 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well HEP-150-12A Power Supply 150W 12V | 150W | 12V | 12.5A | IP65 | $87.40 | View |
| Mean Well HEP-150-24A Power Supply 151.2W 24V | 151.2W | 24V | 6.3A | IP65 | $87.40 | View |
