Mean Well HLG-100H-20AB Power Supply 100W 20V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HLG-100H-20AB Power Supply 100W 20V - Adjustable and Dimm...
The HLG-100H is a 100W Mean Well power converter (input range: 90~305VAC).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.8 SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating100 Watt
-
Output Voltage20 Volt
-
Rated Current4.8 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty7 Year
-
Length8.66 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.47 lb
::specification::
Frequently Asked Questions
Can I use the HLG-100H-20AB with a 1-10V dimmer to control 20V LED strip brightness?
Yes. The HLG-100H-20AB accepts 1-10V and PWM dimming signals, so you can pair with a standard 1-10V wall dimmer or automation controller to smoothly adjust 20V LED strip brightness. It also has a built-in potentiometer for setting the maximum output level.
Is the HLG-100H-20AB a good choice for smart-home controlled LED lighting?
Yes. Its dimming input (1-10V/PWM) can be driven by most smart-home lighting controllers or building automation systems that output a 1-10V signal. Combined with 100W at 20V and adjustable output, it gives you both automated and manual brightness control.
Can the HLG-100H-20AB power 20V architectural LED cove lighting?
Yes. With 100W at 20V and built-in dimming capability, it is well suited for cove lighting where smooth brightness control is important. The adjustable output lets you fine-tune the drive level to match the specific LED strip installed in the cove.
How many meters of 20V LED strip can the HLG-100H-20AB drive?
The HLG-100H-20AB delivers up to 100W. Divide 100 by your strip's wattage per meter to find the maximum length. A strip rated at 8W/m, for example, could run up to 12.5 meters (100W / 8W per meter). Always check your strip's rated power per meter before sizing.
Can I mount the HLG-100H-20AB in a sheltered outdoor location?
Yes. Its IP65 rating protects against dust and low-pressure water jets, making it suitable for covered outdoor areas such as porches, carports, and awnings. Avoid locations where it could be submerged or directly exposed to heavy rain — use an IP67 model like the HLG-100H-20B for those conditions.
