Mean Well HLG-120H-48AB Power Supply 120W 48V - Adjustable and Dimmable

Name: Mean Well HLG-120H-48AB Power Supply 120W 48V - Adjustable and Dimmable
Brand: Mean Well
SKU: HLG-120H-48AB
Price: 55.06 USD
Availability: InStock

premium quality7 years warrantyaluminium casinghigh efficiency

SKU:

HLG-120H-48AB

$55.06 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

The HLG-120H is a 120W Mean Well power converter (input range: 90~305VAC, operating temperature: -40~+80℃).

Key Features

✓ Input voltage range: 90~305VAC
✓ DC output voltage adjustable ±10%
✓ 3.75KVAC reinforced I/O isolation
✓ Cooling by free air convection
✓ Wide operating temperature: -40~+80℃
✓ Protections: Short circuit / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: Note.8 SAFETY &
✓ 3 years warranty

Brand

Mean Well
Series

HLG Series
Power Rating

120 Watt
Output Voltage

48 Volt
Rated Current

2.5 Ampere
Input Voltage

90V~305V
No of Output

1
Dimming Control

10V PWM,1-10V,Built-in Potentiometer,Resistance
Standards Met

CB,CCC,CE,EAC,PSE,RCM,TUV,UL
Operation Mode

Constant Current,Constant Voltage
Operating Temperature

-40°C~80°C
Warranty

7 Year
Length

8.66 in
Width

2.68 in
Height

1.53 in
Weight

2.47 lb

Frequently Asked Questions

Can I use the HLG-120H-48AB with a 1-10V dimmer to control 48V LED strip brightness?

Yes. The HLG-120H-48AB accepts 1-10V and PWM dimming signals, so you can pair with a standard 1-10V wall dimmer or automation controller to smoothly adjust 48V LED strip brightness. It also has a built-in potentiometer for setting the maximum output level.

Is the HLG-120H-48AB a good choice for smart-home or building-automation controlled LED lighting?

Yes. Its dimming input (1-10V/PWM) can be driven by most smart-home controllers or BMS systems that output a 1-10V signal. Combined with 120W at 48V and adjustable output, it gives you both automated and manual brightness control for 48V LED fixtures.

Can the HLG-120H-48AB power 48V architectural LED cove or accent lighting?

Yes. With 120W at 48V and built-in dimming capability, it is well suited for cove and accent lighting where smooth brightness control is important. The adjustable output lets you fine-tune the drive level to match the specific LED strip or fixture installed.

Can I use the HLG-120H-48AB for dimmable 48V LED signage?

Yes. The 120W output at 48V can drive LED sign modules, and the 1-10V/PWM dimming input lets you reduce brightness at night or during off-peak hours. This is useful for commercial signs that need scheduled dimming to comply with local lighting ordinances.

How many meters of 48V LED strip can the HLG-120H-48AB drive?

The HLG-120H-48AB delivers up to 120W. Divide 120 by your strip's wattage per meter to find the maximum length. A strip rated at 12W/m, for example, could run up to 10 meters (120W / 12W per meter = 10m). Always check your strip's rated power per meter before sizing.

Is the HLG-120H-48AB rated for semi-outdoor locations like covered walkways?

Yes. Its IP65 rating protects against dust and low-pressure water jets, making it suitable for covered walkways, porches, or soffits where it is not directly exposed to sustained rainfall. For fully exposed outdoor locations, consider the IP67-rated HLG-120H-48B with dimming.
