Mean Well HLG-185H-C700AB Power Supply 200.2W 700mA - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HLG-185H-C700AB Power Supply 200.2W 700mA - Adjustable an...
The HLG-185H is a 185W Mean Well power converter (input range: 90~305VAC, operating temperature: -40~+90℃).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: EN/AS/NZS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG-C Series
-
Power Rating200.2 Watt
-
Output Voltage286 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,PSE,RCM,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty7 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can I use the HLG-185H-C700AB to power dimmable LED high-bay fixtures?
Yes. The HLG-185H-C700AB provides 700mA constant current at up to 200.2W with both an adjustable output and a 1-10V/PWM dimming input. This makes it ideal for high-bay LED fixtures where you need to adjust brightness based on daylight harvesting or occupancy, as long as the fixture's forward voltage falls within 143-286V.
Is the HLG-185H-C700AB a good fit for dimmable commercial LED signage?
Yes. The 700mA constant current output at up to 286V can drive long series strings of LED modules used in channel letter signs and illuminated panels. The built-in dimming input lets you schedule day/night brightness levels, and the adjustable output trims the current to your modules' optimal point.
Can I use the HLG-185H-C700AB for large LED downlight arrays with automated dimming?
Yes. At 200.2W it can power substantial downlight arrays whose series string voltage totals between 143V and 286V. The 1-10V/PWM dimming input integrates with building automation or lighting control systems for smooth brightness scheduling, and the adjustable output lets you calibrate current delivery.
How do I know if my LED fixture is compatible with the HLG-185H-C700AB?
Your fixture must be designed for 700mA constant current drive, and its total forward voltage must fall within the CC voltage range of 143-286V. The number of LEDs in series depends on each LED's individual forward voltage. Verify your fixture's rated drive current and total string voltage before selecting this driver.
Can the HLG-185H-C700AB operate in a cold outdoor environment?
Yes. The operating temperature range extends from -40°C to +90°C, so it handles extreme cold and high ambient heat. The IP65 rating protects against dust and low-pressure water jets, making it suitable for sheltered outdoor enclosures in harsh climates. For direct rain exposure, consider the IP67-rated HLG-185H-C700B.
What is the difference between the HLG-185H-C700AB and the HLG-240H-C700AB?
Both are constant current LED drivers at 700mA with adjustable output and dimming input. The HLG-185H-C700AB delivers 200.2W with a CC voltage range of 143-286V, while the HLG-240H-C700AB delivers 249.9W with a CC voltage range of 178-357V. Choose based on the total forward voltage and power requirement of your LED string.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other HLG-185H Models
2 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well HLG-185H-C500A Power Supply 200W 500mA - Adjustable | 200W | 400V | 0.5A | IP65 | $53.29 | View |
| Mean Well HLG-185H-C1400A Power Supply 200.2W 1400mA - Adjustable | 200.2W | 143V | 1.4A | IP65 | $53.29 | View |
