Mean Well HLG-80H-20 Power Supply 80W 20V
The HLG-80H is a 80W Mean Well power converter (input range: 90~305VAC).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.8 SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating80 Watt
-
Output Voltage20 Volt
-
Rated Current4 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty7 Year
-
Length7.7 in
-
Width2.42 in
-
Height1.53 in
-
Weight1.85 lb
::specification::
Frequently Asked Questions
Can I use the HLG-80H-20 to power 20V LED strip lighting outdoors?
Yes. The HLG-80H-20 outputs 20V at up to 4A (80W) and carries an IP67 waterproof rating. It can be installed in fully exposed outdoor locations where rain and moisture are present without requiring an additional weatherproof enclosure.
Is the HLG-80H-20 suitable for driving 20V LED modules in commercial signage?
Yes. At 80W and 20V, it can power 20V channel letters, cabinet signs, or light boxes. The wide 90-305VAC input accepts most commercial mains supplies worldwide, and the IP67 rating supports outdoor sign installations.
Can the HLG-80H-20 run 20V LED panel lights in a workshop or warehouse?
Yes, as long as the panels operate at 20V and their combined load does not exceed 80W. The unit runs in constant-current mode with a CC voltage range of 12-20V, so it can accommodate panels that draw slightly below the full 20V during operation.
How many meters of 20V LED strip can the HLG-80H-20 power?
That depends on the strip's rated power per meter. The HLG-80H-20 supplies up to 80W at 20V. For example, if your strip draws 8W/m, you could run up to 10 meters (80W / 8W per meter = 10m). Always check your strip's rated power per meter and keep total load at or below 80W.
Can the HLG-80H-20 be installed in a wet-location junction box or directly exposed to rain?
Yes. Its IP67 waterproof rating protects against temporary submersion in water up to 1 meter. It can be mounted in outdoor enclosures, wet-location junction boxes, or left fully exposed to rain without additional weatherproofing.
