Can I use the HEP-150-12 for a 12V industrial control or embedded system?

Yes, if the equipment needs constant-voltage 12V DC and the total load is within 12.5A and 150W. That makes it suitable for 12V industrial controls, embedded systems, and automation accessories designed for a 12V bus.

Is the HEP-150-12 a good fit for 12V DC equipment in mobile or vibration-prone environments?

It can be a good fit where 12V constant-voltage output is required, because it provides 12.5A and is rated to withstand 10G vibration. The fanless design also avoids a moving part in harsher installations.

Can this model support a 12V CCTV, access control, or low-voltage automation load?

It can support 12V DC loads up to 12.5A and 150W, so it fits many centralized 12V equipment applications when the power budget stays inside those numbers. Buyers should match it only to equipment that explicitly requires constant-voltage 12V input.

Is the HEP-150-12 suitable for fully exposed outdoor locations?

Yes, this version is listed as IP68, which is a stronger environmental rating than IP65 water-resistant or IP67 waterproof models. It is also rated for -55°C to +70°C operation, which supports very cold and very hot environments.

How does the HEP-150-12 compare with other HEP-150 voltages?

Within the HEP-150 group, the listed outputs are 12V at 12.5A and 150W, 15V at 10A and 150W, 24V at 6.3A and 151.2W, 36V at 4.2A and 151.2W, 48V at 3.2A and 153.6W, and 54V at 2.8A and 151.2W. The HEP-150-12 has the lowest output voltage and the highest output current in that subgroup.

Mean Well HEP-150-12 Power Supply 150W 12V

The HEP-150 is a 150W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC, operating temperature: -60~+80°C).

Key Features

✓ 228mm width — DIN rail TS-35 compatible
✓ Input voltage range: 90~305VAC
✓ Cooling by free air convection
✓ Wide operating temperature: -60~+80°C
✓ Protections: Short circuit / Overload / Over voltage / Over temperature
✓ Active PFC — meets international energy efficiency regulations
✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-150 Blank type), EAC TP TC 004
✓ 3 years warranty

Brand

Mean Well
Series

HEP Series
Power Rating

150 Watt
Output Voltage

12 Volt
Rated Current

12.5 Ampere
Input Voltage

90V~305V
No of Output

1
Standards Met

CB,CE,EAC,UL
Operation Mode

Constant Voltage
Operating Temperature

-55°C~70°C
Warranty

6 Year
Length

8.98 in
Width

2.68 in
Height

1.53 in
Weight

2.54 lb

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well HEP-150-12A Power Supply 150W 12V	150W	12V	12.5A	IP65	$87.40	View
Mean Well HEP-150-24A Power Supply 151.2W 24V	151.2W	24V	6.3A	IP65	$87.40	View
