Mean Well HRP-100-15 Power Supply 105W 15V
The HRP-100 is a 100W Mean Well DIN rail power converter with a 159mm profile (input range: 85~264VAC).
Key Features
- ✓ 159mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 85~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHRP Series
-
Power Rating105 Watt
-
Output Voltage15 Volt
-
Rated Current7 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~60°C
-
Warranty5 Year
-
Length6.26 in
-
Width3.82 in
-
Height1.5 in
-
Weight1.23 lb
::specification::
Frequently Asked Questions
Can I use the HRP-100-15 for 15V industrial instrumentation or test equipment?
Yes, if the equipment requires a constant 15V DC supply and the total load stays within 105W and 7A. Its 85-264VAC input is useful for equipment that may be deployed across different AC mains environments.
Is the HRP-100-15 a fit for 15V automation electronics inside a control cabinet?
It can be used for 15V automation electronics when the system is designed for constant-voltage 15V input and does not exceed 7A or 105W. The compact 159.0 × 97.0 × 38.0 mm size can also help in enclosure-based equipment layouts.
Can this model power embedded systems or industrial peripherals that need 15V DC?
It is appropriate for 15V embedded or industrial peripheral loads that need fixed-voltage output and remain within 15V, 7A, and 105W. This model is not a constant-current unit, so the connected equipment should be intended for constant-voltage operation.
Is the HRP-100-15 meant for outdoor use or only protected indoor environments?
The operating temperature range is -40°C to +60°C, so the temperature spec supports use in demanding protected environments. No IP rating is listed in the provided data, so outdoor exposure is not established by these specs alone.
When should I choose the HRP-100-15 instead of a higher-power 15V HRP model?
The HRP-100-15 is rated for 15V, 7A, and 105W. If your 15V load needs more than 7A or more than 105W, the listed higher-power options are HRP-150-15 at 10A and 150W, HRP-200-15 at 13.4A and 201W, HRP-300-15 at 22A and 330W, HRP-450-15 at 30A and 450W, and HRP-600-15 at 43A and 645W.
