Mean Well IRM-02-24 Switching Power Supply 2W 24V 83mA - Encapsulated
The IRM-02 is a 2W Mean Well power converter (input range: 85~305VAC).
Key Features
- ✓ Input voltage range: 85~305VAC
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesIRM Series
-
Power Rating2 Watt
-
Output Voltage24 Volt
-
Rated Current0.08 Ampere
-
Input Voltage85V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length1.33 in
-
Width0.87 in
-
Height0.59 in
-
Weight0.05 lb
::specification::
Frequently Asked Questions
Can I use the IRM-02-24 to power a small 24V industrial sensor or transmitter from AC mains?
Yes, this model is a 24V constant-voltage power supply rated at 2W with 0.08A output. That makes it suitable for small 24V industrial electronics that stay within those output limits and need wide 85-305VAC input support.
Is this power supply a fit for low-power 24V building automation or control PCB circuits?
It can be a fit for compact 24V control circuitry where the total load stays within 2W and 0.08A. Its miniature encapsulated construction and PCB mounting style make it better aligned with embedded or board-level automation products than higher-power 24V loads.
Can the IRM-02-24 be used in a compact embedded device that needs 24V DC internally?
Yes, for embedded equipment that requires a regulated 24V constant-voltage output and does not exceed 2W. The compact 33.7 × 22.2 × 15.0 mm size and 0.024 kg weight support use in space-constrained internal assemblies.
Would this work for a small 24V relay, indicator, or interface circuit inside industrial equipment?
It is intended for low-power 24V DC loads, so it can suit small relay-interface, indicator, or signaling circuits that remain within 2W and 0.08A. It is not positioned for larger 24V devices that need more current than this output provides.
Is the IRM-02-24 suitable for outdoor or washdown environments?
No outdoor or washdown rating is listed for this model. The published environmental information is an operating range of -30°C to +85°C, and the miniature encapsulated PCB-mount style is better suited to protected indoor equipment enclosures.
