Mean Well LDB-600LW DC/DC LED Driver CC 600mA - Buck-boost
The LDB is a Mean Well power converter (input range: 2~40VDC).
Key Features
- ✓ Input voltage range: 2~40VDC
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over temperature
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLDB Series
-
Power Rating18 Watt
-
Output Voltage30 Volt
-
Rated Current0.6 Ampere
-
Input Voltage9V~28V
-
No of Output1
-
Dimming ControlPWM
-
Standards MetCE,EAC
-
Operation ModeConstant Current
-
Operating Temperature-40°C~71°C
-
Warranty3 Year
-
Length1.25 in
-
Width0.8 in
-
Height0.48 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can the LDB-600LW be used with a 600mA LED downlight engine?
Yes, this driver outputs 600mA constant current, so it suits LED downlight engines rated for 600mA. The connected LED load needs to stay within the 2-30V constant current range and the 18W maximum output.
Is the LDB-600LW a fit for small high-brightness LED arrays?
Yes, it can be used for compact LED arrays that are specified for 600mA constant current operation. It is not a constant voltage driver, so it should not be used as a substitute for a fixed-voltage LED power supply.
Can this model work for outdoor signage lighting?
It can be a fit for outdoor signage modules that need 600mA constant current and stay within the 2-30V CC range. The IP67 Waterproof rating also supports applications where exposure to dust or water is a concern.
What LED load range does the LDB-600LW support?
This model delivers 600mA constant current with a 2-30V CC output range. The number of LEDs depends on the forward voltage of each LED, so compatibility should be checked by total LED voltage rather than by a fixed LED count.
Is the LDB-600LW rated for wide temperature exposure?
Yes, it is specified for operation from -40°C to +71°C. Combined with the IP67 Waterproof rating, that makes it suitable for use in exposed or demanding environments.
