Mean Well LPC-20-700 Power Supply 20W 700mA
The LPC-20 is a 20W Mean Well power converter (input range: 9~48V, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 9~48V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL879, UL1310 , CSA C22.2 No. 207-M89(except for LPC-20-350), CAN/CSA C22.2 No. 223-M91(except for LPC-20-350), TUV EN60950-1, IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLPC Series
-
Power Rating21 Watt
-
Output Voltage30 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EAC,TUV,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length4.65 in
-
Width1.38 in
-
Height1.02 in
-
Weight0.49 lb
::specification::
Frequently Asked Questions
Can I use the LPC-20-700 for a 700mA LED downlight?
This model is suitable for a LED downlight when the LED module requires 700mA constant current and its total forward voltage is within 9-30V. With 21W output power, it is aimed at smaller downlight loads rather than larger multi-module fixtures. It should be matched to constant current LEDs, not constant voltage fixtures.
Is the LPC-20-700 suitable for compact signage lighting?
It can work for compact signage lighting if the LED assembly is designed for 700mA constant current and the full load falls inside the 9-30V CC range. Because this is a constant current driver, it is meant for current-regulated LED boards rather than constant voltage signage systems. Its 21W rating keeps it in the small-load category.
Can this driver power a small LED array with higher current demand?
Yes, provided the small LED array is built for 700mA constant current operation and needs between 9V and 30V across the full load. Compared with a lower-current driver, this model is better suited to arrays that need more drive current but still stay in a lower voltage range. It is not intended for constant voltage LED products.
How do I check whether my LEDs are compatible with the LPC-20-700?
Your LED load needs to require 700mA constant current, and the total forward voltage of the connected LEDs must fall within the 9-30V CC output range. The number of LEDs depends on the forward voltage of each LED, so compatibility cannot be reduced to one fixed LED count. This driver should not be used where the load expects constant voltage output.
How does the LPC-20-700 differ from the LPC-20-350 and LPC-35-700?
The LPC-20-700 delivers 700mA with a 9-30V CC range and 21W. The LPC-20-350 delivers 350mA with a 9-48V range and 16.8W, while the LPC-35-700 delivers 700mA with a 9-48V range and 33.6W. Across those siblings, the differences are output current, constant current voltage window, and available power.
Is the LPC-20-700 appropriate for outdoor or washdown-prone locations?
It carries an IP67 waterproof rating, so it is designed for environments where sealing against dust and water matters. The rated operating temperature is -30°C to +70°C, which supports use across a broad temperature range. That makes it more flexible for exposed conditions than non-sealed indoor-only drivers.
