Mean Well LPC-60-1050 Power Supply 60W 1050mA
The LPC-60 is a 60W Mean Well DIN rail power converter with a 162.5mm profile (input range: 9~48V, operating temperature: -30~+70℃).
Key Features
- ✓ 162.5mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 9~48V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL1310, CAN/CSA C22.2 No. 223-M91(for LPC-60-1750 only), IP67, IEC60950-1:2005+A2:2013
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLPC Series
-
Power Rating50.4 Watt
-
Output Voltage48 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,CSA,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.4 in
-
Width1.67 in
-
Height1.26 in
-
Weight0.88 lb
::specification::
Frequently Asked Questions
Can I use the LPC-60-1050 for a higher-output LED downlight?
Yes, if the downlight is a constant current design that requires 1050mA. This model covers a 9-48V CC range and up to 50.4W, so it fits higher-output downlights that need more power than a 31.5W or 33.6W driver.
Is the LPC-60-1050 a good match for compact LED signage assemblies?
It can be, provided the signage assembly is built for constant current operation at 1050mA. The load must stay within the 9-48V output range and 50.4W maximum, and the IP67 housing supports use in signage exposed to weather.
Can the LPC-60-1050 power a small LED array with more output than a 700mA driver?
Yes, this model delivers 1050mA constant current, which is higher than a 700mA driver. It is suitable for small LED arrays that are specified for 1050mA and stay within 9-48V and 50.4W.
How do I know if the LPC-60-1050 is compatible with my LED string?
Compatibility depends on the LED string being a constant current 1050mA load with a total forward voltage inside the 9-48V CC range. The actual number of LEDs depends on each LED's forward voltage, so this should not be matched by LED count alone, and it is not a constant voltage driver.
Can the LPC-60-1050 be used in wet or cold locations?
The driver is IP67 rated and specified for -30°C to +70°C operation. That makes it suitable for demanding indoor or outdoor environments where moisture and temperature range matter.
