Mean Well LPC-60-1750 Power Supply 60W 1750mA
The LPC-60 is a 60W Mean Well DIN rail power converter with a 162.5mm profile (input range: 9~48V, operating temperature: -30~+70℃).
Key Features
- ✓ 162.5mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 9~48V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL1310, CAN/CSA C22.2 No. 223-M91(for LPC-60-1750 only), IP67, IEC60950-1:2005+A2:2013
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLPC Series
-
Power Rating59.5 Watt
-
Output Voltage34 Volt
-
Rated Current1.75 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,CSA,EAC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length6.4 in
-
Width1.67 in
-
Height1.26 in
-
Weight0.88 lb
::specification::
Frequently Asked Questions
Can I use the LPC-60-1750 for a high-current LED downlight?
Yes, if the downlight requires 1750mA constant current. This driver operates across 9-34V and provides up to 59.5W, so it is meant for lower-voltage, higher-current LED loads within that range.
Is the LPC-60-1750 suitable for dense LED signage modules?
It can be, as long as the signage module string is designed for constant current at 1750mA. The load must fit inside the 9-34V CC range and 59.5W maximum, and the IP67 rating supports exposed sign environments.
Can the LPC-60-1750 power a small LED array with a lower voltage requirement?
Yes, this model is better suited to constant current LED arrays that need 1750mA and stay within 9-34V. Compared with higher-voltage variants, its range is narrower on voltage but higher on current.
How do I tell if my LED load is compatible with the LPC-60-1750?
Your LED load needs to be a constant current 1750mA load with total forward voltage in the 9-34V range. The exact number of LEDs depends on each LED's forward voltage, so compatibility should be checked by total forward voltage rather than a fixed LED count; it is not for constant voltage LED products.
Can the LPC-60-1750 handle outdoor or wide-temperature conditions?
Yes, it is rated IP67 and specified for operation from -30°C to +70°C. Those ratings make it appropriate for challenging environments where water resistance and temperature range are part of the selection criteria.
