Mean Well HLG-185H-C1050AB Power Supply 199.5W 1050mA - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HLG-185H-C1050AB Power Supply 199.5W 1050mA - Adjustable ...
The HLG-185H is a 185W Mean Well power converter (input range: 90~305VAC, operating temperature: -40~+90℃).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: EN/AS/NZS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG-C Series
-
Power Rating199.5 Watt
-
Output Voltage190 Volt
-
Rated Current1.05 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,ENEC,PSE,RCM,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty7 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can I use the HLG-185H-C1050AB to drive high-voltage LED downlight arrays?
Yes. The HLG-185H-C1050AB delivers a constant 1050mA across a 95-190V output range, making it well suited for series strings of high-voltage LED downlights. At 199.5W, it can handle substantial arrays, and the built-in adjustment potentiometer lets you fine-tune output current to match the LEDs' optimal drive level.
Is the HLG-185H-C1050AB suitable for large LED signage modules that require constant current?
Yes. Its 1050mA constant-current output with a 95-190V compliance range can power long series strings of signage LED modules. The adjustable output and 1-10V/PWM dimming input allow brightness scheduling for day and night operation, which is common in commercial signage installations.
Can I dim the HLG-185H-C1050AB for architectural LED lighting projects?
Yes. The AB suffix indicates both an adjustment potentiometer and a dimming interface that accepts 1-10V or PWM signals. This makes it compatible with most building automation and lighting control systems. At 199.5W and 1050mA, it can drive architectural LED fixtures wired in series where smooth dimming is required.
Can this driver power a series string of LED COB modules for high-bay lighting?
Yes, provided the total forward voltage of your COB string falls within the 95-190V compliance range and each module is rated for 1050mA drive current. The number of COBs you can connect in series depends on each module's individual forward voltage. The IP65 rating also allows installation in damp industrial environments.
Can I install the HLG-185H-C1050AB in a sheltered outdoor location?
Yes. Its IP65 water-resistant rating protects against dust and low-pressure water jets, making it suitable for covered outdoor areas, canopy-mounted fixtures, or ventilated enclosures. The operating temperature range of -40°C to +90°C covers extreme hot and cold climates.
How does the HLG-185H-C1050AB compare to other constant-current models in the HLG-185H-C series?
The HLG-185H constant-current family includes C500 (500mA, 200-400V), C700 (700mA, 143-286V), C1050 (1050mA, 95-190V), and C1400 (1400mA, 71-143V) variants, all rated around 200W. Lower-current models have higher compliance voltage for longer LED strings, while higher-current models suit LEDs that need more drive current in shorter strings. The AB suffix on each means it has both output adjustment and dimming input.
