Mean Well PLM-25-500, 500mA Constant Current with PFC - Terminal Block
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PLM-25-500, 500mA Constant Current with PFC - Terminal Block
The PLM-25 is a 25W Mean Well DIN rail power converter with a 145mm profile (input range: 110~295VAC, operating temperature: -30~+45℃).
Key Features
- ✓ 145mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 110~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12(for Blank type only); ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14,GB19510.1 (for E type only) ,EAC TP TC 004, IP30
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLM Series
-
Power Rating25 Watt
-
Output Voltage56 Volt
-
Rated Current0.5 Ampere
-
Input Voltage110V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty2 Year
-
Length5.71 in
-
Width1.5 in
-
Height0.87 in
-
Weight0.28 lb
::specification::
Frequently Asked Questions
Can I use the PLM-25-500 for a 500mA LED downlight?
Yes, if the downlight is designed for constant current operation at 500mA and the LED load falls within the 30-50V constant-current range. It is a constant current driver, so it should not be substituted for a constant voltage LED supply.
Is the PLM-25-500 suitable for small LED arrays that need moderate forward voltage?
It is suitable for constant current LED arrays requiring 500mA where the total forward voltage stays within 30-50V. The driver is rated for 25W output.
Can this model be used with constant current signage light engines?
Yes, when the signage light engine is specified for 500mA constant current and the combined LED forward voltage is within 30-50V. It is not intended for constant voltage modules that expect a fixed DC output.
How should I size LEDs for the PLM-25-500?
Match it to a 500mA constant current LED load whose total forward voltage stays within the 30-50V CC range. The number of LEDs depends on each LED's forward voltage, so the proper check is total load voltage at 500mA rather than a fixed LED count.
What are the differences between the 25W PLM models around this output level?
For the 25W PLM group, PLM-25-1050 is 1050mA with a 14-24V CC range at 25.2W, PLM-25-700 is 700mA with a 21-36V CC range at 25.2W, PLM-25-500 is 500mA with a 30-50V CC range at 25W, and PLM-25-350 is 350mA with a 42-72V CC range at 25.2W. The matching E versions use the same current, CC range, and wattage values for each output option.
