Mean Well RPS-400-12-TF Green Power Supply W 12V 20.8A - Medical Power Supply
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RPS-400-12-TF Green Power Supply W 12V 20.8A - Medical Po...
The RPS-400-12 is a 400W Mean Well power converter (input range: 80~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 80~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 4KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: IEC60601-1, TUV EN60601-1, EAC TP TC 004 , UL ANSI / AAMI ES60601-1 (3.1 version), CAN/CSA-C22.2 No. 60601-1:14 - Edition 3
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRPS Series
-
Power Rating249.6 Watt
-
Output Voltage12 Volt
-
Rated Current20.8 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,SHIDE
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length5.12 in
-
Width3.39 in
-
Height2.62 in
-
Weight1.28 lb
::specification::
Frequently Asked Questions
Can I use the RPS-400-12-TF for a 12V industrial PC or embedded controller system with multiple peripherals?
Yes, if the full 12V load remains within 20.8A and 249.6W. Its constant-voltage 12V output is appropriate for larger embedded or industrial computing assemblies powered from an 80-264VAC input.
Is this model suitable for centralized 12V power in automation or instrumentation equipment?
It is a fit for centralized 12V DC distribution inside automation or instrumentation equipment when all connected loads require constant 12V. The available output is 20.8A with a total power rating of 249.6W.
Can the RPS-400-12-TF be used in medical electronics that need a 12V rail?
Yes, this unit is listed as a medical power supply and includes medical safety approval with extreme low leakage current in the features. The medical device or subsystem must still match the 12V output and stay within 20.8A and 249.6W.
Is the RPS-400-12-TF intended for outdoor cabinets or exposed equipment?
No outdoor or wet-location rating is shown because no IP rating is listed in the provided specs. It should be considered for indoor protected use, even though the operating temperature range is -30°C to +70°C.
How is the RPS-400-12-TF different from the other 12V RPS-400 versions?
Electrically, the RPS-400-12, RPS-400-12-C, RPS-400-12-SF, and RPS-400-12-TF are all rated 249.6W at 12V and 20.8A. The main listed difference here is form factor: this TF version is 130.0 x 86.0 x 66.5 mm and 0.58 kg, while the C version is 130.0 x 86.0 x 43.0 mm and 0.51 kg, and the SF version is 160.0 x 86.0 x 43.0 mm and 0.64 kg.
