Mean Well SI06W8-03 8:1 Ultra-Wide Input DC-DC Regulated Converter,...
The SI06W8 is a 6W Mean Well power converter (input range: 9~75Vdc, operating temperature: -40~+90℃).
Key Features
- ✓ Input voltage range: 9~75Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSI06W8 Series
-
Power Rating6 Watt
-
Output Voltage3.3 Volt
-
Rated Current0.00 Ampere
-
Input Voltage9V~75V
-
No of Output1
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
What is the Mean Well SI06W8-03 designed for?
The Mean Well SI06W8-03 is a regulated DC-DC converter for applications that need a stable 3.3V DC output from a very wide DC input range. Its 6W rating and compact 1 inch by 1 inch DIP package make it suited to space-constrained industrial and embedded power designs.
What makes the SI06W8-03 different from standard DC-DC converters?
A key differentiator is its 8:1 ultra-wide input range, which gives it more flexibility than converters built for narrower input windows. This model also combines 3KVDC input-to-output isolation, no minimum load requirement, and protection coverage for overload, over temperature, over voltage, short circuit, and input under voltage.
Is the SI06W8-03 suitable for harsh temperature environments?
Yes. Mean Well specifies an operating temperature range of -40 to +90 degrees C, which supports use in demanding industrial environments. Buyers still need to confirm that the rest of the system is rated for the same conditions, but this converter itself is designed for wide-temperature operation.
Does this converter require a minimum load to regulate properly?
No. The SI06W8-03 is specified with no minimum load required, which can simplify product selection in low-load or variable-load designs. That makes it useful where the output demand may fluctuate or remain very light during parts of operation.
What are the main specifications of the Mean Well SI06W8-03?
This model is a single-output regulated DC-DC converter rated for 6W with a 3.3V output. It includes up to 86% efficiency, 3KVDC input/output isolation, an industry-standard DIP 1 inch by 1 inch package, optional remote ON/OFF control, and a 3-year warranty.
Does the SI06W8-03 include built-in compliance and protection features?
Yes. Mean Well states that it complies with BS EN/EN55032 radiated Class A without additional components, and it includes continuous short-circuit, overload, over-temperature, over-voltage, and input under-voltage protection. Those features help make it a stronger fit for reliability-focused industrial equipment.
