Mean Well SI06W8-03 8:1 Ultra-Wide Input DC-DC Regulated Converter,...
The SI06W8 is a 6W Mean Well power converter (input range: 9~75Vdc, operating temperature: -40~+90℃).
Key Features
- ✓ Input voltage range: 9~75Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSI06W8 Series
-
Power Rating6 Watt
-
Output Voltage3.3 Volt
-
Rated Current0.00 Ampere
-
Input Voltage9V~75V
-
No of Output1
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
What is the main use case for the Mean Well SI06W8-03 DC-DC converter?
This model is intended for regulated DC-DC power conversion in compact industrial and embedded equipment. Its 6W power rating, single 3.3V output, and 8:1 ultra-wide input range make it a practical choice where input voltage can vary significantly across systems.
What output does the SI06W8-03 provide?
The SI06W8-03 is a single-output regulated converter rated for 3.3V output and 6W power. It is designed for applications that need a stable low-voltage DC rail from a much wider DC input range.
How does the 8:1 ultra-wide input range benefit this model?
An 8:1 input range gives this converter more flexibility in systems where the source voltage may fluctuate or differ across deployments. That makes the SI06W8-03 easier to standardize across multiple industrial or mobile power environments than a narrower-input converter.
Is the SI06W8-03 suitable for harsh temperature environments?
Yes. This model is specified for operation from -40°C to +90°C, which supports use in demanding industrial environments with wide ambient temperature variation. That range is useful for equipment exposed to cold starts or elevated internal enclosure temperatures.
Does this converter require a minimum load to operate properly?
No. The SI06W8-03 is specified with no minimum load requirement, which can simplify use in systems with variable or intermittent power draw. That can be helpful in control, sensing, or standby applications where the load is not always constant.
What protection and isolation features are included in the SI06W8-03?
This model includes protection for short circuit, overload, over temperature, over voltage, and input under voltage. It also provides 3KVDC input-to-output isolation, which is valuable in designs that need added electrical separation between power domains.
What compliance and reliability features does this model offer?
The SI06W8-03 is stated to comply with BS EN/EN55032 radiated Class A without additional components. It also offers efficiency up to 86% and is backed by a 3-year warranty, supporting use in long-life industrial applications.
