Mean Well DKMW20F-12 DC-DC Converter - 20W - 9~36V in ±12V out
The DKMW20F is a 20W Mean Well. power converter. and an input range of 9~36Vdc.
Key Features
- ✓ Input voltage range: 9~36Vdc
- ✓ 1.5KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSKMW Series
-
Power Rating20 Watt
-
Output Voltage12 Volt
-
Rated Current0.83 Ampere
-
Input Voltage9V~36V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
Can I use the DKMW20F-12 in a 12V industrial control system with a wider input range?
This model is intended for constant 12V output and accepts a 9-36VAC input range, which is broader than the DKM10E series. It is suitable for applications that need 12V and stay within its 20W rating and listed 830A output current.
Is the DKMW20F-12 a good fit for embedded or automation equipment that runs on 12V?
It can fit embedded or automation electronics that need a fixed 12V rail rather than a higher-voltage output. The main product limits are 20W total power and a 9-36VAC input range.
Would the DKMW20F-12 work for compact 12V monitoring and interface modules?
Yes, the compact 25.4 × 25.4 × 10.2 mm form factor supports dense electronics layouts. It is built for constant-voltage 12V use where the load fits within 20W.
Can the DKMW20F-12 handle colder or hotter operating environments?
The specified operating temperature is -40°C to +85°C, so it covers a wide industrial temperature range. No IP rating is listed, so the specs do not verify outdoor installation or exposure to water and dust.
What is the difference between the DKMW20F-12 and DKMW20F-15?
Both listed DKMW20F models are 20W converters with a 9-36VAC input range, 25.4 × 25.4 × 10.2 mm dimensions, 0.018 kg weight, CE certification, 3-year warranty, and -40°C to +85°C operation. The DKMW20F-12 is listed at 12V and 830A, while the DKMW20F-15 is listed at 15V and 660A.
