Mean Well SLW05C-15 DC-DC Converter - 5W - 36~72V in 15V out
The SLW05C is a 5W Mean Well power converter (operating temperature: -25~+71℃).
Key Features
- ✓ 1KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -25~+71℃
- ✓ Protections: Short circuit
- ✓ Safety approvals: ℃ ℃ , 10 ~ 95% RH ℃ (0 ~ 50 -25 ~ +105 ± 0.03% / 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesSLW Series
-
Power Rating5 Watt
-
Output Voltage15 Volt
-
Rated Current0.33 Ampere
-
Input Voltage36V~72V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCE,EMC,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~71°C
-
Warranty2 Year
-
Length2 in
-
Width1 in
-
Height0.44 in
-
Weight0.07 lb
::specification::
Frequently Asked Questions
Can I use the SLW05C-15 in a 48V industrial control panel that needs 15V DC for a small auxiliary circuit?
Yes. The SLW05C-15 accepts 36-72VAC input and provides a constant-voltage 15V output rated at 5W, which makes it suitable for small 15V auxiliary circuits within that input and power range. It is intended for low-power conversion rather than higher-wattage 15V loads.
Is the SLW05C-15 a fit for embedded or automation electronics that require isolated 15V rail conversion from a higher-voltage source?
It can fit small embedded or automation subcircuits that need a 15V constant-voltage output at 5W. The 36-72VAC input range is suited to higher-voltage source conditions within that window. Buyers should match the load to the 15V output and 5W rating.
Can this 15V DC-DC converter power a compact 15V instrumentation or interface stage inside industrial equipment?
Yes, for compact 15V stages that stay within the converter's 5W capacity. Its small 50.8 × 25.4 × 11.27 mm size also helps where board or enclosure space is limited. The output mode is constant voltage, which is appropriate for electronics expecting a regulated 15V rail.
Would the SLW05C-15 make sense for a small 15V signaling or monitoring circuit in automation hardware?
Yes, if the signaling or monitoring circuit requires 15V constant-voltage power and the total demand stays within 5W. The unit is compact at 0.032 kg and sized for space-constrained assemblies. It is not the right choice when the application needs a different output voltage from this series.
How does the SLW05C-15 compare with the other SLW05C models?
All SLW05C models in this group are rated at 5W. The SLW05C-15 outputs 15V and lists 333A, while the SLW05C-12 outputs 12V and 417A, the SLW05C-09 outputs 9V and 556A, and the SLW05C-05 outputs 5V and 1000A. The main selection difference is the required output voltage and the listed output current for each model.
Is the SLW05C-15 suitable for outdoor or harsh-environment use?
The published specs show an operating temperature range of -25°C to +71°C, but they do not list an IP rating. Without an IP rating in the provided specs, it should not be assumed to be outdoor-rated or protected against water and dust. It is better matched to enclosed equipment where that temperature range is acceptable.
