Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well UHP-350-12 Power Supply 350.4W 12V
The UHP-350 is a 350W Mean Well DIN rail power converter with a 220mm profile (input range: 90~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ 220mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ DC OK relay contact output
- ✓ Safety approvals: WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION EMC IMMUNITY MTBF 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes UL 62368-1,TUV EN62368-1,EN60335-1,CCC GB4943,BSMI CNS14336-1,EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesUHP Series
-
Power Rating350.4 Watt
-
Output Voltage12 Volt
-
Rated Current29.2 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length8.66 in
-
Width2.44 in
-
Height1.22 in
-
Weight1.5 lb
::specification::
Frequently Asked Questions
Can I use the UHP-350-12 for a 12V industrial control panel or automation enclosure?
Yes, this model provides constant-voltage 12V output at up to 29.2A, with 350.4W total power. That makes it appropriate for 12V industrial control, automation support circuits, and embedded cabinet power where the load is designed for 12V DC.
Is the UHP-350-12 suitable for 12V CCTV, access control, or security hardware?
It can be used where the connected equipment requires a 12V constant-voltage source and the total demand stays within 350.4W and 29.2A. This output class is often considered for centralized 12V security and monitoring systems.
Can this power supply run 12V embedded electronics or low-voltage machine accessories?
Yes, the 12V output and 350.4W capacity make it relevant for embedded electronics, low-voltage controllers, and machine accessories built around 12V DC. Its 220.0 × 62.0 × 31.0 mm low-profile housing also helps in tighter equipment spaces.
Is the UHP-350-12 okay for outdoor installations or only indoor use?
The operating temperature range is -30°C to +70°C, but no IP rating is listed in the provided specs. That supports use across a broad temperature range, while outdoor exposure or direct moisture resistance should not be assumed from this data.
How does the UHP-350-12 compare with other UHP-350 output options?
In the UHP-350 family, the listed versions are 198W 3.3V 60A, 252W 4.2V 60A, 300W 5V 60A, 350.4W 12V 29.2A, 351W 15V 23.4A, 350.4W 24V 14.6A, 351W 36V 9.75A, and 350.4W 48V 7.3A. The main difference is output voltage and current while staying in the same slim, fanless series class.
