Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well XDR-480E-12 Economical Ultra Slim Din Rail Power Supply 3...
Key Features
- ✓85~264Vac input range
- ✓Global certificates in multi-fields(ITE 62368-1, Industrial 61558-1/-2-16, 61010)
- ✓48mm slim width
- ✓High efficiency up to 96% and no-load power dissipation<1.2W
- ✓Built-in constant current limiting circuit
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Fanless design, cooling by free air convection
- ✓Overvoltage category III (OVC III)
- ✓-40°~+70°C wide range operation temperature (>+50°C derating)
- ✓Operating altitude up to 5000 meters
- ✓Built-in DC OK relay contact
- ✓Can be installed on DIN rail TS-35/7.5 or 15
- ✓3 years warranty
-
BrandMean Well
-
SeriesMean Well XDR Series
-
Power Rating360 Watt
-
Output Voltage12 Volt
-
Rated Current30 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,KC
-
Operating Temperature-40°C~70°C
-
Warranty3 Year
-
Length4.92 in
-
Width1.89 in
-
Height4.93 in
-
Weight1.96 lb
::specification::
Frequently Asked Questions
What output does the Mean Well XDR-480E-12 provide?
The XDR-480E-12 is a 12V DC DIN rail power supply rated for 360W. Its rated output current is 30A, making it suitable for 12V systems within that power requirement.
What types of applications is the XDR-480E-12 intended for?
This model is designed for DIN rail power supply applications where a compact 12V DC source is required. Its listed certifications cover ITE, industrial, and 61010-related use cases, which makes it relevant for many commercial and industrial equipment environments.
Why choose the XDR-480E-12 over a wider DIN rail power supply?
The XDR-480E-12 has a slim 48mm width, which is useful when cabinet or rail space is limited. It also provides up to 96% efficiency and operates fanlessly by free air convection.
Can the XDR-480E-12 operate in high or low temperatures?
Yes. The specified operating temperature range is -40°C to +70°C, with derating above +50°C. This makes it suitable for environments that require a wide temperature operating range.
What protections are included with the XDR-480E-12?
The listed protections include short circuit, overload, over voltage, and over temperature protection. It also includes a built-in constant current limiting circuit.
Is the XDR-480E-12 suitable for higher-altitude operation?
The XDR-480E-12 is specified for operation at altitudes up to 5000 meters. It also carries Overvoltage Category III, which is noted in the product specifications.
What input voltage range does the XDR-480E-12 support?
The specified AC input range is 85 to 264Vac. This wide input range supports use across many mains power environments where the product's ratings and approvals are appropriate.
What warranty and weight are listed for this model?
The XDR-480E-12 has a listed warranty period of 3 years. Its listed weight is 0.89 kg.
