ENVO ZigBee Motion + Light + Temperature + Humidity 4-in-1 Sensor
Features:
- Zigbee 3.0 compliant
- PIR motion sensor, long detection range
- Temperature sensing, automates your home heating or cooling
- Humidity sensing, automates your home humidifying or dehumidifying
- Illminance measuring, daylight harvesting
- Autonomous sensor-based control
- OTA firmware upgrade
- Wall mount installation
- Can be use for indoor applications
- Cost-effective solution for energy savings
- Energy code compliance
- Robust mesh network
- Compatible with universal Zigbee platforms that support sensor
General Specification
Zigbee Protocol
Zigbee 3.0
Operate Voltage
3VDC (2*AAA Batteries)
Standby Consumption
10uA
Radio Frequency
2.4 GHz
Wireless Range
100 feet (30m) Line of Sight
Radio Certification
CE
Dimension (LxWxH)
55.5x55.5x23.7mm
-
BrandEnvo
-
Operating Temperature0°C~40°C
-
Warranty5 Year
-
Length2.19 in
-
Width2.19 in
-
Height0.93 in
::specification::
Frequently Asked Questions
What does the ENVO ZigBee Motion + Light + Temperature + Humidity 4-in-1 Sensor measure?
This model combines four sensing functions in one device: PIR motion detection, illuminance measurement, temperature sensing, and humidity sensing. It is designed to support automation decisions based on occupancy and surrounding environmental conditions.
What applications is this 4-in-1 ZigBee sensor suited for?
It is well suited for indoor commercial or smart-building applications that need occupancy-based and environment-based automation. Typical use cases include daylight harvesting, energy-saving lighting control, and temperature or humidity-based HVAC automation.
Is this sensor compatible with standard ZigBee platforms?
Yes, this sensor is Zigbee 3.0 compliant and is described as compatible with universal Zigbee platforms that support sensors. Compatibility still depends on whether the platform supports this type of motion, light, temperature, and humidity sensor device.
Can this sensor be used outdoors or in harsh environments?
No, this model is specified for indoor applications. Its listed operating temperature range is 0°C to 40°C, so it is intended for normal indoor environmental conditions rather than exposed outdoor use.
How is this model different from a standard motion-only sensor?
Unlike a motion-only sensor, this model adds light, temperature, and humidity sensing in the same unit. That makes it a stronger fit for projects that want broader automation logic and energy-saving control from a single ZigBee sensor.
What are the key operating specs for this sensor?
The sensor uses Zigbee 3.0 at 2.4 GHz and is powered by 3VDC from two AAA batteries. It has a standby consumption of 10uA, a wireless range of up to 100 feet (30 m) line of sight, and dimensions of 55.5 x 55.5 x 23.7 mm.
