Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well UHP-500R-36 Power Supply 500.4W 36V - Redundant

slim and low profile, fanless design, built-in DC OK and redundant function

SKU:

UHP-500R-36

$111.13 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

Slim and Low profile (31mm)

Fanless design, 500W convection

Withstand 300VAC surge input for 5 seconds

Built-in active PFC function

150% peak load capability(100ms)

-20~+70℃ working temperature

Protections: Short circuit / Overload / Over voltage / Over temperature

DC OK active signal and redundant function(option)

Operating altitude up to 5000 meter

LED indicator for power on

3 years warranty

General Specification

AC input voltage range	90~264VAC 127~370VDC
AC inrush current	Cold start :30A/115VAC 60A/230VAC
Overload protection	110~140% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
Over voltage protection	12V:13.2~15.6V, 15V:16.5~19.5V, 24V:26.4~31.2V, 36V:39.6~46.8V, 48V:52.8~62.4V Protection type :Shut down O/P voltage, re-power on to recover
Setup, rise, hold up time	1000ms, 50ms/230VAC/115VAC at full load; 12ms/115VAC, 230VAC
Withstand voltage	I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.25KVAC
Working temperature	-20~+70℃ (Refer to “Derating Curve)
Safety standards	UL60950-1, TUV EN60950-1, CCC GB4943, EAC TP TC 004,BSMI CNS14336-1 approved, Design refer to EN60335-1, EN61558-1,-2-16
EMC standards	Compliance to EN55032, GB/T9254, Class B, EN61000-3-2,-3, EAC TP TC 020, BSMI CNS13438; Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61000-6-2 (EN50082-2), heavy industry level, criterial A,EAC TP TC 020
Dimension (LxWxH)	232×81×31mm
Packing	0.905Kg;16pcs/15.48Kg

Specifications

Brand

Mean Well
Series

UHP Series
Power Rating

500.4 Watt
Output Voltage

36 Volt
Rated Current

13.9 Ampere
Input Voltage

90V~264V
No of Output

1
Standards Met

BSMI,CB,CCC,CE,EAC,TUV,UL
Operation Mode

Constant Voltage
Operating Temperature

-30°C~70°C
Warranty

3 Year
Length

9.13 in
Width

3.19 in
Height

1.22 in
Weight

2 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the UHP-500R-36 for 36V industrial motion or automation equipment?

Yes, this model is a 36V constant voltage power supply rated for 500.4W and 13.9A. It is suited to 36V industrial or automation equipment where the total load stays within 13.9A and 500.4W.

Is this power supply suitable for a 36V control system or embedded platform?

It can be a fit for 36V DC systems that require constant voltage operation. The supply provides up to 13.9A at 36V, which can support multiple 36V loads in one enclosure when the total demand stays within 500.4W.

Can the UHP-500R-36 be used for 36V industrial communications or edge equipment?

Yes, if the equipment is designed for a 36V DC input. This unit delivers 36V constant voltage with 500.4W total power and includes built-in DC OK and redundant function features.

Is the UHP-500R-36 a good choice for slim machine enclosures?

The published dimensions are 232.0 × 81.0 × 31.0 mm and the features list includes a slim, low-profile, fanless design. Those characteristics make it relevant where a 36V supply must fit inside compact industrial housings.

Can this 36V model be used outdoors or in unheated spaces?

The operating temperature range is -30°C to +70°C, so the temperature spec supports use in cold and hot locations. No IP rating is shown in the provided data, so the specs do not verify suitability for exposed outdoor environments.

How does the UHP-500R-36 compare to the other redundant UHP-500R versions?

The listed UHP-500R redundant options are 4.2V 336W 80A, 5V 400W 80A, 12V 500.4W 41.7A, 15V 501W 33.4A, 24V 501.6W 20.9A, 36V 500.4W 13.9A, and 48V 501.6W 10.45A. The UHP-500R-36 is the 36V version with 500.4W output and 13.9A current.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well UHP-500R-5 Power Supply 400W 5V - Redundant	400W	5V	80A	Indoor	$111.13	View
Mean Well UHP-500R-48 Power Supply 501W 48V - Redundant	501.6W	48V	10.45A	Indoor	$111.13	View
Mean Well UHP-500R-4.2 Power Supply 336W 4.2V - Redundant	336W	4.2V	80A	Indoor	$111.13	View
Mean Well UHP-500R-24 Power Supply 501.6W 24V - Redundant	501.6W	24V	20.9A	Indoor	$111.09	View
Mean Well UHP-500R-15 Power Supply 501W 15V - Redundant	501W	15V	33.4A	Indoor	$111.13	View
Mean Well UHP-500R-12 Power Supply 500.4W 12V - Redundant	500.4W	12V	41.7A	Indoor	$111.09	View
