Boxco S-Series 11.02 x 14.96 x 5.12 Inches(280x380x130mm) Plastic E...
Description
Description
For Boxco S-Series, Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.
Features
- Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
- Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
- Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
- Cover Bolt Attachment Point – Screw thread was made in injection molding to ensure maximum strength
Specifications
Specifications
-
BrandBoxco
-
SeriesBoxco S Series
-
MaterialABS
-
Base ColorGrey
-
Cover ColorGrey
-
Standards MetCE,TUV,UL
-
Operating Temperature-40°C~70°C
-
Warranty1 Year
-
Length11.02 in
-
Width14.96 in
-
Height5.12 in
-
Weight3.19 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What are the key specifications of the Boxco S-Series BC-AGS-283813 enclosure?
This model is a Boxco S-Series plastic enclosure with overall dimensions of 11.02 x 14.96 x 5.12 inches (280 x 380 x 130 mm). It is made from ABS, has a grey cover, uses a screw-type closure, and carries IP67 and IK08 ratings. The listed product weight is 1.448 kg.
Is this enclosure suitable for outdoor environments?
Yes, this S-Series enclosure is described as having an ultraviolet stabilizer added for outdoor usage. That helps reduce visible color change over long-term exposure. Its IP67 rating also supports use in demanding environments where dust and water resistance are important.
What kind of environmental protection does this enclosure provide?
This enclosure is rated IP67 for protection against dust ingress and water exposure, and IK08 for impact resistance. The product description also notes a precision-injected gasket designed to support waterproof and dust-proof performance. Its operating temperature range is -40°C to 70°C.
What applications is this ABS enclosure best suited for?
This model is well suited for protecting industrial or commercial electronics that need a durable non-metallic enclosure. The product description specifically mentions anti-static material for sensitive electronic instruments. Its size, impact resistance, and environmental ratings make it a practical option for indoor or outdoor control and protection applications.
Does this enclosure support internal mounting hardware or equipment plates?
Yes, the enclosure includes mounting plate attachment points so an internal mounting plate can be fixed tightly onto brass inserted injection molding. The description also states that pre-molded mounting screw nuts are provided for securing DIN rail or other equipment. These built-in features help support heavier internal components.
What makes this screw-type enclosure different from a basic plastic box?
Compared with a basic plastic enclosure, this model combines IP67 and IK08 ratings with UV-stabilized ABS and anti-static material. It also includes molded features such as cover bolt attachment points, mounting plate attachment points, and pre-molded screw nuts. Those details make it more suitable for demanding industrial enclosure applications.
What warranty is listed for this enclosure?
The listed warranty period for this model is 1 year. That applies specifically to the BC-AGS-283813 product entry provided here. Buyers with project-specific coverage requirements should still confirm final warranty terms at time of purchase.
