Boxco S-Series 7.48 x 14.96 x 5.12 Inches(190x380x130mm) Plastic En...
Description
Description
For Boxco S-Series, Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.
Features
- Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
- Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
- Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
- Cover Bolt Attachment Point – Screw thread was made in injection molding to ensure maximum strength
Specifications
Specifications
-
BrandBoxco
-
SeriesBoxco S Series
-
MaterialABS
-
Base ColorGrey
-
Cover ColorTransparent
-
Standards MetCE,TUV,UL
-
Operating Temperature-40°C~70°C
-
Warranty1 Year
-
Length7.48 in
-
Width14.96 in
-
Height5.12 in
-
Weight2.54 lb
File Downloads
File Downloads
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Frequently Asked Questions
What applications is this Boxco S-Series enclosure suited for?
This model is intended for protecting electronic and control equipment in industrial and commercial environments where a sealed plastic enclosure is needed. Its ABS construction, transparent cover, and impact and ingress ratings make it a practical choice for outdoor panels, monitoring devices, and other housed components that need visibility without opening the cover.
What are the exact dimensions of this enclosure?
This enclosure measures 7.48 x 14.96 x 5.12 inches, which corresponds to 190 x 380 x 130 mm. Those dimensions make it a relatively long enclosure within the S-Series, giving more internal space than compact junction-style boxes.
Is this enclosure suitable for outdoor or washdown environments?
This model is rated IP67, which indicates strong protection against dust ingress and temporary water exposure. The product description also states that an ultraviolet stabilizer is added for outdoor usage, helping reduce visible color change over time.
How durable is the enclosure against impact and harsh handling?
This enclosure carries an IK08 impact rating and is described as being made from high impact resistant material. Boxco also notes the design helps resist breakage during machining processes such as hole and press processing.
Does the transparent cover make this model different from opaque versions?
Yes. The transparent cover allows inspection of indicators, displays, or internal components without opening the enclosure, which can be useful in applications where visual checks are common. Buyers choosing between cover types often select this version when internal visibility matters more than a fully opaque housing.
What equipment mounting features are included in this enclosure?
The enclosure includes internal mounting plate attachment points and pre-molded mounting screw nuts for securing accessories such as DIN rail or other internal equipment. The description also highlights brass inserted injection molding for tightly fixing the internal mounting plate when heavier equipment is used.
What temperature range can this enclosure handle?
This model is specified for use from -40 degrees C to 70 degrees C. That range makes it suitable for many indoor and outdoor industrial environments where temperature swings are a concern.
