Boxco Terminal Box 4-pole with Waterproof Connector 1.57 x 2.36 x 0.94 Inches(40 x 60 x 24mm) IP67, IK08, ABS, Grey Cover

The BC-AGG-4PC is a compact enclosure box intended for protecting terminal block components in applications that need a small, durable housing. This model includes a 4-pole terminal box format and a waterproof connector, making it suitable for space-constrained industrial or commercial use.

This Boxco model measures 1.57 x 2.36 x 0.94 inches, which is 40 x 60 x 24 mm. Its compact size makes it a practical choice where enclosure space is limited.

This model is rated IP67, which indicates strong protection against dust ingress and temporary water exposure. That makes it a good option for environments where moisture and contamination resistance are important.

The BC-AGG-4PC carries an IK08 impact rating, which indicates resistance to mechanical impact in demanding environments. It is also made from flame-retardant ABS material for added durability and material safety.

This model is specified for use from -40 °C to 70 °C. That range supports use in both cold and moderately hot operating conditions, depending on the surrounding application requirements.

The BC-AGG-4PC combines a compact 40 x 60 x 24 mm enclosure size with a 4-pole terminal box configuration, IP67 protection, and IK08 impact resistance. It also features a grey cover and molded knockouts on each end, which helps differentiate it within Boxco's enclosure box range.
