Description
Description
- Dimming interface: 0-10V (1-10V/10V PWM/RX)
- Push Dim
- T-PWM digital dimming
- With soft-on and fade in function
- visual more comfortable.
- Automatic recognition of 0-10V
- 1-10V input signal
- Innovative thermal management technology
- intelligent power life protection.
- Dimming range:0~100%
- LED start at 0.01% possible.
- 0-100% flicker-free
- High Frequency Exemption
- Multi-current & wide voltage
- suitable for different power LED.
- Over load / Over-heat / Short circuit protection
- Suitablefor internal lights application for I/II/III
Specifications
Specifications
-
BrandLtech
-
SeriesLtech 0/1-10V Series
-
Power Rating20 Watt
-
Output Voltage58 Volt
-
Rated Current0.2 Ampere
-
Input Voltage100V~277V
-
No of Output1
-
Dimming Control0-10V,1-10V
-
Standards MetCB,CCC,CE,EMEC,RCM,ROHS,TUV
-
Operation ModeConstant Current
-
Operating Temperature-30°C~55°C
-
Warranty5 Year
-
Length6.89 in
-
Width1.73 in
-
Height1.18 in
-
Weight0.4 lb
