Ltech LT-3060-8A PWM Constant Voltage Repeater - RGB
Your order will be processed within 24 hours
Ltech LT-3060-8A PWM Constant Voltage Repeater - RGB
Description
Description
LED power repeater is suitable for all of LTECH power types(DIM,CT,RGB) LED controller’s power expansion. It accepts PWM control. The controlled LED quantities would be double or triple by adding one more power repeater. Unlimited power repeaters could be connected theoretically. It has Short circuit/Over current/anti-reverse connection safety protection. Constant voltage and constant current LED power repeater can be mixed connect, facilitate different voltage, high power and low power LED lamps controlled by one controller.
Specifications
Specifications
-
BrandLtech
-
SeriesLtech Repeater
-
Power Rating576 Watt
-
Output Voltage24 Volt
-
Rated Current24 Ampere
-
Input Voltage5V~24V
-
No of Output3
-
Dimming ControlNone
-
Standards MetCE,FCC,RCM
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~65°C
-
Warranty5 Year
-
Length5.83 in
-
Width3.43 in
-
Height0.91 in
-
Weight0.84 lb
