LTECH TD-30-300-900-EFP1 30W 300mA ~ 900mA CC Triac LED Driver - Se...
- Support Leading edge (Triac)
- Trailing edge (ELV) and Push Dimmer.
- Built-in SCM
- dimming curve and smoothing time can be customized.
- T-PWM digital dimming
- present a perfect visual experience.
- Dimming range: 0~100%
- dimming depth: Max. 0.01%.
- Flicker-free (IEEE 1789)
- achieve the level of exemption assessment.
- Innovative thermal management technology
- intelligent power life protection.
- Multi-current & wide voltage
- suitable for different power LED.
- Over load / Over-heat / Short circuit protection
- recover automatically.
- Class 2 power supply. Full protective plastic housing.
- Compliant with Safety Extra Low Voltage standard.
- Suitable for internal lights application for Ⅰ/Ⅱ/Ⅲ
-
BrandLtech
-
SeriesLtech Triac Series
-
Power Rating30 Watt
-
Output Voltage45 Volt
-
Rated Current0.3 Ampere
-
Input Voltage200V~240V
-
No of Output1
-
Dimming ControlPWM
-
Standards MetCE,ROHS,SELV
-
Operation ModeConstant Current
-
Operating Temperature-20°C~50°C
-
Warranty5 Year
-
Length6.89 in
-
Width1.89 in
-
Height1.18 in
-
Weight0.02 lb
::specification::
Frequently Asked Questions
What kind of dimming control does the LTECH TD-30-300-900-EFP1 support?
This model is designed for phase-cut dimming and supports leading edge (Triac), trailing edge (ELV), and push dimmer control. Its description also notes T-PWM digital dimming, a 0 to 100% dimming range, and very fine dimming depth for smoother low-level adjustment.
Is the TD-30-300-900-EFP1 a constant current LED driver?
Yes. The TD-30-300-900-EFP1 is a constant current LED driver with selectable output current from 300 mA up to 900 mA. That makes it better suited to LED loads that need a controlled current rather than a fixed constant-voltage output.
What output range should buyers check for this 30W LED driver?
This model is rated at 30W and lists an output voltage of 45V, with selectable constant-current output from 300 mA to 900 mA. Buyers should confirm that their fixture or LED load falls within those driver limits before choosing this model.
Is this LED driver a good fit for projects that need smooth, low-flicker dimming?
It is intended for dimming-sensitive LED applications where smooth control matters. The product description states flicker-free performance to IEEE 1789 exemption level and highlights customizable dimming curve and smoothing time, which helps differentiate it from basic phase-cut drivers.
What operating temperature range does the TD-30-300-900-EFP1 support?
The specified operating temperature range is -20 degrees C to 50 degrees C. That makes it suitable for many indoor commercial and architectural lighting environments, provided the installation conditions stay within that range.
Does the LTECH TD-30-300-900-EFP1 include a warranty?
Yes. This model lists a 5-year warranty period. For B2B buyers, that can be useful when comparing lifecycle value and support expectations across dimmable constant current driver options.
