Mean Well DHP-1UT-A 3200~12800W 1U Distributed Power/Charger System
The DHP-1UT is a 12800W Mean Well. power converter. and an input range of 90~264VAC.
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Remote ON/OFF control
- ✓ Safety approvals: 20 ~ 90% RH non-condensing ℃ , 10 ~ 95% RH non-condensing -40 ~ +85 ± ℃ ℃ ) (0 ~ 50 0.03%/ 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes UL62368-1, TUV EN62368-1
- ✓ 3 years warranty
-
BrandMean Well
-
Warranty5 Year
-
Length19 in
-
Width15.75 in
-
Height1.73 in
-
Weight12.13 lb
::specification::
Frequently Asked Questions
What is the Mean Well DHP-1UT-A used for?
The DHP-1UT-A is a 1U distributed power and charger system designed for 19-inch rack applications. It is intended for higher-power installations that need a compact rack shelf supporting up to four 3200W modules for a total system capacity of up to 12800W.
How much power can the DHP-1UT-A system support?
This model is built for systems from 3200W up to 12800W, depending on how many 3200W modules are used in the rack shelf. Mean Well specifies support for four modules with active current sharing in a 1U profile.
Is the DHP-1UT-A suitable for standard rack mounting?
Yes. The DHP-1UT-A is a 1U, 19-inch rack shelf intended for rack-mounted power system use. Its listed dimensions are 400 x 482.6 x 44 mm with the mounting bracket, or 400 x 440 x 44 mm without the bracket.
What input range does the DHP-1UT-A accept?
The DHP-1UT-A supports a universal AC input range of 90 to 264VAC and also accepts 127 to 370VDC. That wide range makes it suitable for facilities that need flexible input compatibility across different power environments.
Does the DHP-1UT-A support system monitoring or communication protocols?
Yes. Mean Well lists built-in PMBus support on this model, with CANBus available as an option. That makes it relevant for buyers who need monitoring or control capability in larger managed power systems.
Can the DHP-1UT-A operate in demanding temperature conditions?
The specified working temperature range is -30°C to +70°C, subject to the output derating curve. This gives it a broad operating range for industrial or controlled equipment-room environments where temperature tolerance matters.
What differentiates the DHP-1UT-A from a standard standalone power supply?
The DHP-1UT-A is not a basic standalone supply; it is a rack-mount distributed power and charger platform built to hold multiple 3200W modules in a 1U chassis. Its hot-swap support, programmable output voltage and current, and active current sharing are the key distinctions for higher-power system design.
What warranty and compliance information is available for the DHP-1UT-A?
Mean Well specifies a 5-year warranty for the DHP-1UT-A. The unit is also listed with UL62368-1, CSA C22.2, and TUV EN62368-1 safety approvals, along with EMC compliance to EN55032 Class B and EN61000-4 series standards.
