Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Mean Well DLC03A-15 DC-DC Converter - 3W - 9~18V in ±15V out

SKU:

DLC03A-15

$9.76 USD

Shipping calculated at checkout.

Notify me when it's back in stock

Your order will be processed within 24 hours

Description

Features

DIP16 package with industry-standard pinout

Operating temperature range -40~+85°C

2:1 wide input range

No minimum load required

Comply to BS EN/EN55032 radiated Class B without additional components

High efficiency up to 82%

Protection: Short circuit(continuous)/Overload/Input under voltage

1.5KVDC I/O isolation

3 years warranty

General Specification

Voltage accuracy	±2%
Vibration	10~500Hz, 2G 10min./1 cycle, the period for 60 min, each along X, Y, and Z axes
Cooling	Free-air convection
Short circuit protection	Continuous, auto-recovery
Working temperature	-40°C to +85°C
EMC	Compliance to EN55032 class B, EN61000-4-2,3,4,5,6,8
Temp. Coefficient	0.03% / ℃ (0 ~ 80℃)
Dimension (LxWxH) (mm)	22.113.88.55mm (0.870.540.34 inch)
Potting material	UL 94V-0 rated

Specifications

Brand

Mean Well
Series

DLC Series
Power Rating

3 Watt
Output Voltage

15 Volt
Rated Current

0.1 Ampere
Input Voltage

9V~18V
No of Output

2
Dimming Control

None
Standards Met

CE,EAC
Operation Mode

Constant Voltage
Operating Temperature

-40°C~85°C
Warranty

3 Year
Length

0.83 in
Width

0.54 in
Height

0.34 in
Weight

0.01 lb

File Downloads

::specification::

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Frequently Asked Questions

Can I use the DLC03A-15 for industrial or embedded hardware that needs a 15V auxiliary supply?

This model provides constant 15V output and operates from a 9-18VAC input range. Its 3W rating makes it suitable for low-power auxiliary rails in industrial, embedded, or instrumentation equipment that specifically needs 15V.

Is the DLC03A-15 suitable for analog or signal-conditioning electronics that use 15V power?

It can fit low-power signal-conditioning, interface, or analog support circuits that require a constant 15V rail. The 3W rating defines it as a small auxiliary converter rather than a supply for larger 15V loads.

Can this converter be used in compact monitoring or control devices with limited board area?

The housing is 21.1 × 13.8 × 8.55 mm and the unit weighs 0.0045 kg, so it is sized for compact electronics. That makes it practical where a low-power 15V rail is needed without using much board space.

Is the DLC03A-15 meant for outdoor use or only protected enclosures?

The converter is rated for operation from -40°C to +85°C, so it supports wide ambient temperature conditions. No IP rating is listed, so the provided specifications do not confirm outdoor or exposed-environment suitability.

What are the key differences between the DLC03A-15 and the other DLC03A versions?

All three DLC03A models are rated at 3W with a 9-18VAC input range. The difference is output: the DLC03A-05 is 5V at 300A, the DLC03A-12 is 12V at 125A, and the DLC03A-15 is 15V at 100A.

Model	Power	Voltage	Current	IP Rating	Price
Mean Well DLC03C-15 DC-DC Converter - 3W - 36~75V in ±15V out	3W	15V	0.1A	Indoor	$9.29	View
Mean Well DLC03C-12 DC-DC Converter - 3W - 36~75V in ±12V out	3W	12V	0.12A	Indoor	$9.76	View
Mean Well DLC03C-05 DC-DC Converter - 3W - 36~75V in ±5V out	3W	5V	0.3A	Indoor	$9.76	View
Mean Well DLC03B-15 DC-DC Converter - 3W - 18~36V in ±15V out	3W	15V	0.1A	Indoor	$9.76	View
Mean Well DLC03B-12 DC-DC Converter - 3W - 18~36V in ±12V out	3W	12V	0.12A	Indoor	$9.76	View
Mean Well DLC03B-05 DC-DC Converter - 3W - 18~36V in ±5V out	3W	5V	0.3A	Indoor	$9.76	View
Mean Well DLC03A-12 DC-DC Converter - 3W - 9~18V in ±12V out	3W	12V	0.12A	Indoor	$9.76	View
Mean Well DLC03A-05 DC-DC Converter - 3W - 9~18V in ±5V out	3W	5V	0.3A	Indoor	$9.76	View
