Mean Well ELG-100-C700AB Power Supply 100W 700mA - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ELG-100-C700AB Power Supply 100W 700mA - Adjustable and D...
The ELG-100 is a 100W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: IEC62386-101, 102, 207 for DA-Type only
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELG-C Series
-
Power Rating100.1 Watt
-
Output Voltage149 Volt
-
Rated Current0.7 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,RCM,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length7.83 in
-
Width2.48 in
-
Height1.4 in
-
Weight1.87 lb
::specification::
Frequently Asked Questions
Can I use the ELG-100-C700AB in a dimmable LED downlight system where output current also needs to be adjusted?
Yes. The ELG-100-C700AB combines both adjustable output current and dimming capability in a single driver. It delivers 700mA constant current over a 71–143V CC range at 100.1W, and the dimming input allows brightness to be controlled from an external signal while the adjustment feature lets the baseline current be tuned during commissioning.
Is the ELG-100-C700AB appropriate for outdoor or damp-location luminaire installations?
The ELG-100-C700AB is rated IP65, meaning it is protected against low-pressure water jets but is not rated for temporary immersion. It is suitable for damp indoor locations and sheltered outdoor enclosures, but not for direct outdoor exposure without housing. For harsher outdoor exposure, the IP67-rated ELG-100-C700B covers the same wattage and current with added waterproof protection.
How does the ELG-100-C700AB compare to the ELG-100-C700A?
Both models are rated at 100.1W with 700mA constant current, a 71–143V CC range, and IP65 protection. The ELG-100-C700AB adds dimming capability on top of the current-adjustment feature found in the ELG-100-C700A. If your installation requires both run-time dimming and a fixed current adjustment, the AB variant is needed; if only adjustment is required, the A variant is sufficient.
Can the ELG-100-C700AB drive LED modules in an architectural lighting system that requires dimming?
Yes. The driver's built-in dimming input is designed for this scenario, allowing integration into an architectural or hospitality lighting control system. The constant current output of 700mA within the 71–143V range keeps LED drive conditions stable across the dimming range.
What LED string voltage range must my LED load fall within to use the ELG-100-C700AB?
The LED string's combined forward voltage must fall within 71V to 143V for the driver to regulate properly in constant current mode. The quantity of LEDs in that string depends on each LED's individual forward voltage; there is no universal count.
Does the ELG-100-C700AB support universal AC input voltages?
Yes. The driver accepts 100–305VAC input, covering 120V (North America), 230V (Europe and most of Asia), and higher industrial voltages. No input switching or rewiring is required when moving between regions.
