Mean Well ELG-200-C1400A Power Supply 200W 1400mA - Adjustable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ELG-200-C1400A Power Supply 200W 1400mA - Adjustable
The ELG-200 is a 200W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: (type”HL”), CSA C22.2 No. 250.13-12;IEC/EN/AS/NZS 61347-1, IEC/EN/AS/NZS 61347-2-13 UL8750 EAC TP TC 004;BIS IS15885(for 12/12B/24/24B/36/36A/42A/48/48A/54A only) GB19510.14,GB19510.1; IP65 or IP67; KC61347 1 KC61347 2 13
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELG-C Series
-
Power Rating198.8 Watt
-
Output Voltage160 Volt
-
Rated Current1.4 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming ControlBuilt-in Potentiometer
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,RCM,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length9.61 in
-
Width2.8 in
-
Height1.48 in
-
Weight2.69 lb
::specification::
Frequently Asked Questions
Can the ELG-200-C1400A be used to drive outdoor LED street or area lighting fixtures?
Yes. At 198.8W and 1400mA constant current, the ELG-200-C1400A can drive the high-power LED modules found in street lights and area lighting. It is rated IP65, making it water-resistant for typical outdoor luminaire enclosures that are not submerged.
What does the 'A' suffix mean on the ELG-200-C1400A, and how does it differ from the base ELG-200-C1400?
The 'A' suffix indicates that the output current can be adjusted via an external potentiometer or resistor, giving installers flexibility to trim the drive current below the rated 1400mA. The base ELG-200-C1400 (IP67) does not include this trim function and has a higher IP rating; the ELG-200-C1400A is rated IP65.
Is the ELG-200-C1400A appropriate for powering LED modules in an industrial facility with dusty or damp conditions?
Yes. The IP65 rating provides full protection against dust ingress and low-pressure water jets, making the ELG-200-C1400A suitable for industrial environments, covered outdoor installations, and dusty manufacturing spaces.
How many LEDs can I connect in series to the ELG-200-C1400A?
The CC voltage range is 71–142V. The number of LEDs in the series string is determined by each LED's forward voltage; the combined forward voltage of all series LEDs must fall within 71–142V for correct constant current regulation.
Can the ELG-200-C1400A power LED modules in a large illuminated commercial sign?
Yes. The 1400mA constant current output and 198.8W capacity make it suitable for driving higher-current LED sign modules in series. Ensure the total forward voltage of the series string is within the 71–142V CC range.
Does the ELG-200-C1400A support universal input voltage for international deployments?
Yes. With a 100–305VAC input range, this driver operates on 120V, 208V, 240V, 277V, and 230V mains without modification, making it suitable for both North American and international lighting installations.
